ESP32 CAM WiFi Bluetooth Camera Module With OV2640 2MP Camera
The ESP32-CAM is a small size, low power consumption camera module based on ESP32. It comes with an OV2640 camera and provides onboard TF card slot.
The ESP32-CAM can be widely used in intelligent IoT applications such as wireless video monitoring, WiFi image upload, QR identification, and so on.
Features
ESP32-CAM :
- The smallest 802.11b/g/n Wi-Fi BT SoC module.
- Low power 32-bit CPU, can also serve the application processor.
- Up to 160MHz clock speed, summary computing power up to 600 DMIPS.
- Built-in 520 KB SRAM, external 4MPSRAM.
- Supports UART/SPI/I2C/PWM/ADC/DAC.
- Support OV2640 and OV7670 cameras, built-in flash lamp.
- Support image WiFI upload.
- Supports TF card.
- Supports multiple sleep modes.
- Embedded Lwip and FreeRTOS.
- Supports STA/AP/STA+AP operation mode.
- Support Smart Config/AirKiss technology.
- Support for serial port local and remote firmware upgrades (FOTA).
Specifications
- Wireless Module: ESP32-S WiFi 802.11 b/g/n + Bluetooth 4.2 LE module with PCB antenna, u.FL connector, 32Mbit SPI flash, 4MBit PSRAM.
- External Storage: micro SD card slot up to 4GB.
Camera
- FPC connector.
- Support for OV2640 (sold with a board) or OV7670 cameras.
- Image Format: JPEG( OV2640 support only ), BMP, grayscale.
- LED flashlight.
- Expansion: 16x through-holes with UART, SPI, I2C, PWM.
- Misc: Reset button.
- Power Supply: 5V via pin header.
Power Consumption.
- Flash LED off: 180mA @ 5V.
- Flash LED on to maximum brightness: 310mA @ 5V.
- Deep-sleep: 6mA @ 5V min.
- Modem-sleep: 20mA @ 5V min.
- Light-sleep: 6.7mA @ 5V min.
Package Includes
- 1 x ESP32 CAM WiFi Module.
- 1 x OV2640 Camera Module 2MP.
