ESP32-S3 A7670E 4G Development Board, LTE Cat-1 / 2G / WiFi / Bluetooth / Telephone Call / SMS / GNSS Positioning Support
₹3,938.00
All Inclusive, Shipping Calculated at Checkout
Assured Cashback of ₹ 33
B2B GST Credit Available
Price in reward points: 3337
- Stock: 4 in Stock
- SKU: 26749
- Delivery Time
- Bulk & B2B RFQ
ESP32-S3 A7670E 4G Development Board, LTE Cat-1 / 2G / WiFi / Bluetooth / Telephone Call / SMS / GNSS Positioning Support, Suitable For 4G Portable WiFi, Onboard Camera / Speaker / Antenna
The ESP32-S3-A7670E-4G (the development board) is a multifunctional, high-performance microcontroller development board designed by Waveshare. It integrates an A7670E 4G communication module, a universal OV camera interface, a TF card slot, RGB lights, an 18650 battery slot, a battery voltage measurement IC, a solar charging interface, and other peripherals. It employs the ESP32-S3R2, a system-level chip (SoC) that integrates low-power Wi-Fi and BLE5.0. Additionally, it comes with an external 16MB Flash and 2MB PSRAM. The SoC incorporates a hardware encryption accelerator, RNG, HMAC, and digital signature modules, meeting the security requirements of the Internet of Things (IoT).
The A7670E 4G communication module provides mobile network capabilities, enabling functionalities like portable Wi-Fi and IoT data transmission when combined with the ESP32-S3R2. Its various low-power operating modes cater to power consumption demands in IoT, mobile devices, outdoor monitoring, smart home applications, and other scenarios.
Features
- Adopts ESP32-S3R2 chip with high-performance Xtensa® 32-bit LX7 dual-core processor, capable of running at 240 MHz
- Built in 512KB SRAM, 384KB ROM, 2MB of PSRAM, and 16MB Flash memory
- Integrated 2.4GHz Wi-Fi and Bluetooth LE dual-mode wireless communication, featuring superior RF performance
- Equipped with the A7670E-FASE cellular module, supports 4G Cat-1/2G networking, GNSS positioning, telephone calls, SMS, and other functions
- Onboard USB switching IC and DIP switch for switching to use the USB interface of A7670E, suitable for connecting with PC for dial-up internet or debugging of A7670E module
- Onboard lithium battery charging, solar charging, power management, battery capacity measurement, and related protection circuits, supports USB and solar charging with real-time battery capacity measurement
- Onboard 18650 battery holder (18650 battery is NOT included), adapting VBAT pin header for connecting to external 3.7V lithium battery, with anti-reverse protection
- Rich peripheral interfaces such as camera interface, TF card slot, USB port, 38PIN header, etc., easy to expand and achieve various functions
- Onboard multiple DIP switches for camera on/off, switching USB channels to avoid interface conflict, and setting power on/off for some circuits to reduce power consumption
- Comes with GNSS high-precision ceramic antenna, OV2640 camera, mini speaker, acrylic case, etc., easy to develop various applications
- Comes with online development resources and manual (including tutorials, demos for 4G portable WiFi and other IoT examples)
Specifications
COMMUNICATION PARAMETERS
- Frequency Band : LTE-FDD: B1, B3, B5, B7, B8, B20
- Data Transmission : ≤5Mbps(UL), ≤10Mbps(DL)
- GNSS : GPS, BeiDou, GLONASS
OPERATING PARAMETERS
- Power supply method : USB port, 18650 lithium battery holder (18650 battery is NOT included), pin header
- Power input : 5V (USB port / 5V pin header) 3.7~4.2V (18650 lithium battery holder / VBAT pin header)
- Logic Level : 3.3V
Package Includes
- ESP32-S3-A7670E-4G x1
- Transparent acrylic case and screws pack x1
- GNSS ceramic antenna x1
- OV2640 camera x1
- 8Ω 2W 2030 speaker x1
- 40PIN yellow straight pin header x1
- USB Type-A to Type-C cable 1m x1
- FPC antenna x1
- Screwdriver x1
- 2P screw terminal x1
- Double-side tape (4PCS) x1
Provides Portable 4G WiFi Solution
Supports Image Recognition
Supports Charging Via Solar Panel Or USB Port
Application Example
What's On Board
- ESP32-S3R2
- A7670E-FASE
- EA3036C
DC-DC 3-ch power output - ETA6098
Battery charging IC - CN3791
Solar power charging IC - MAX17048G
Battery voltage measurement IC - CH343
UART to USB IC - CH334
USB HUB - W25Q128JVSIQ
External 16MB Flash - FSUSB42UMX
USB switching IC - TXB0104PWR
Voltage translator - Camera 24PIN interface
Compatible with cameras such as OV2640/OV5640 - TF Card Slot
- USB Type-C port
Onboard CH343 And CH334, supports connecting to UART and USB of the ESP32-S3
Onboard USB switching IC and DIP switch for switching to use the USB interface of A7670E - RESET button
- BOOT button
- Nano SIM card slot
- Solar panel input interface
for connecting to 5V/6V/9V/12V/18V solar panel - Onboard antenna
- ESP32-S3 WiFi connector (IPEX 1)
using onboard ceramic antenna by default, supports connecting to external WiFi antenna by modifying solder pad - GNSS connector (IPEX 1)
- LTE connector (IPEX 1)
- WS2812B
RGB LED - Power indicator
- Battery reverse warning indicator
- Solar power input indicator
- Network status indicator
- Solar power input voltage selection
for setting solar panel input voltage:
5V level by default, for connecting with 5.5V / 6V solar power panel, supports modifying solder pads for 9V/12V/18V solar panels - SY8105IADC
External input DC-DC - DIP Switch
CAM: for turning on/off the camera
HUB: for controlling the power supply of USB HUB driver circuit
4G: for controlling the power supply of A7670E module
USB: for switching to the USB channel of A7670E module. - Battery power supply on/off
- 18650 battery holder
- Microphone input
- Speaker output
Pinout Definition
Dimensions
