FT232 USB UART Board (Type A), USB To UART (TTL) Communication Module With USB Type A Connector

This is a FT232 USB To UART (TTL) Communication Module, USB Type A Connector. It Adopts FT232RL, Compatible With 3.3V/5V Logic Level.

User Manual / Datasheet / Example Codes Etc.

Features

Original FT232RL onboard
Supports Mac, Linux, Android, WinCE, Windows 7/8/8.1/10/11...
3 power mode : 5V output, 3.3V output, or powered by target board (3.3V-5V)
3 LEDs: TXD LED, RXD LED, POWER LED
Functional Pins

TXD, RXD, RTS#, CTS# : connected to the onboard soldered pinheaders
The other Pins : accessable on the drill holes (separate pinheaders are also provided for easily connecting to user system, the pitch is compatible with bread boards)

Package Includes

1x FT232 USB UART Board (Type A)
2x 5-pin male pinheader & 5-pin female pinheader
1x 6-pin custom connector jumper wire

How to Use

In the case of working with a MCU:

VCCIO ↔ 3.3V or 5V output (the module is powered from USB, onboard jumper should be shorted to 3.3V or 5V)
GND ↔ GND
TXD ↔ MCU.RX (signal direction: MCU.RX << FT232 << PC.TX)
RXD ↔ MCU.TX (signal direction: MCU.TX >> FT232 >> PC.RX)
RTS ↔ MCU.CTS (signal direction: MCU.CTS << FT232 << PC.RTS)
CTS ↔ MCU.RTS (signal direction: MCU.RTS >> FT232 >> PC.CTS)

Dimensions
