Name: GM66 1D 2D QR / Barcode Scanner Reader Module - Enclosed Design - USB + UART Output - Mounting Plate and Screws Included
Brand: GROW
SKU: 02970
Price: 2714.00 INR
Availability: InStock

GM66 1D 2D QR / Barcode Scanner Reader Module - Enclosed Design - USB + UART Output - Mounting Plate and Screws Included

GROW

GM66 1D 2D QR / Barcode Scanner Reader Module - Enclosed Design - USB + UART Output - Mounting Plate and Screws Included

This product qualifies for Free Surface Shipping !

All orders with value above 1999+GST are eligible for free delivery in Surface mode. (Not applicable for B2B offline orders)

Based on 0 reviews. - Write a review

₹2,714.00

₹2,300.00 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 23
B2B GST Credit Available

Price in reward points: 2300

Stock: 100 in Stock
SKU: 02970
Delivery Time
Bulk & B2B RFQ

Add to Cart

Buy Now

Plan to Buy Later ? Add to Wish List

Features

USB wired barcode scanner to capture 1D, 2D code on labels, paper, mobile phone or computer.
High-efficiency recognization and high upload speed for improving your working efficiency.
With buzzer for reminding you that the scanning successfully or not.
Compatible with USB and UART interface.
Over 180 configurable options
Macro support replace a string in the bar code with another
Programmable preamble postamble and termination strings
Superior reading performance utilizing advanced decoding algorithms

Resources

User Manual

Specifications

Model	GM66
Type	Barcode Scanner
Decoding Ability	1D: EAN- 8,EAN-13,UPC-A,UPC-E,Code 39,Code 93,Code 128, EAN128,Codebar,industrial 2 of 5,Interleave 2 of 5,Matrix 2 of 5,MSI,postal code ect 2D: PDF417,QR Code ,Data Matrix ect
Interface	USB2.0 \ UART
Resolution	0.10mm (4mil)
Operating Voltage	5V
Operating Current	120mA
Weight	31g
Size	62.342.524.5mm
Type of Illuminant	617nm LED(Aimer), 6500K LEDs(Illumination)
LED Indicator	Buzzer and bi-color light: Red-power, Blue-decoding Successfully
Scan Angle	Roll:0-360°, Pitch:±65°or greater, Yaw:±60°or greater
Scanning angle Inclination angle	34°, Elevation angle 26°
Print Contrast	30% minimum reflective difference
Reading Distance	25 - 250mm
Operating Temperature	-20 degrees to 55 degrees
Storage Temperature	-40 degrees to 65 degrees
Temperature Humidity	5% to 95% Relative humidity, Non-condensing
Light Levels	0-85000LUX
