HI-LINK HLK-B0505S-1WR3 5V 1W Isolated DC-DC Converter Power Supply Module

This is an HI-LINK Make B0505S-1WR3 5V 1W Isolated DC-DC Converter Power Supply Module. The HI-LINK B0505S-1WR3 5V 1W Power Supply Module is designed for applications where an isolated voltage is required in a distributed power supply system. They are suitable for: pure digital circuits, low frequency analog circuits, relay-driven circuits and data switching circuits.

Datasheet

Features

Continuous short-circuit protection
Isolated Unregulated
Output Channel : 1
No-load input current as lowas 5mA
Operating ambient temperaturerange:-40℃ to +105℃
High efficiency up to 85%
I/O Isolation test voltage: 1.5kVDC/min,3k VDC/1s
Industry standard pin-out
Compact SIP package

Specifications

Output Voltage : 5V
Function : Buck-boost type
Output Current (Max) : 200mA
Input Voltage(DC) : 4.5V~5.5V
Conversion Type : DC-DC
Output Power : 1W
Maximum Capacitive Load : 2400uF
Insulated Voltage : 1500V
Conversion Efficiency : 85%~88%
