Name: Hi-Link HLK-LD2451 24GHz FMCW Millimeter Wave Radar Module | 100m Vehicle Speed, Distance & Motion Detection Sensor with UART/GPIO
Brand: Hi-Link
SKU: 08416
Price: 876.00 INR
Availability: OutOfStock

New

Hi-Link

Hi-Link HLK-LD2451 24GHz FMCW Millimeter Wave Radar Module | 100m Vehicle Speed, Distance & Motion Detection Sensor with UART/GPIO

Based on 0 reviews. - Write a review

₹876.00

₹742.37 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 7
B2B GST Credit Available

Price in reward points: 742

Stock: 0 in Stock
SKU: 08416
Delivery Time
Bulk & B2B RFQ

Buy Now NOTIFY WHEN AVAILABLE

Plan to Buy Later ? Add to Wish List

Hi-Link HLK-LD2451 24GHz FMCW Millimeter Wave Radar Module | 100m Vehicle Speed, Distance & Motion Detection Sensor with UART/GPIO

HLK-LD2451 is a high sensitivity 24GHz mobile vehicle status sensing module developed by Hi-Link Electronics. Its working principle is to use FMCW FM continuous wave to detect the target within the detection range, combined with radar signal processing, accurate algorithm recognition, to realize high sensitivity vehicle status detection, which can identify the vehicles close or far away, and calculate the output of the target's speed, angle, distance and other auxiliary information.

This product is mainly used in outdoor scenes, sensing whether there is a vehicle close to or far away from the area, real-time output detection results, the longest sensing distance up to 100m. The longest sensing distance can be up to 100 m. Mobile software is provided to easily configure parameters such as sensing distance, speed, target direction and sensitivity to meet different application requirements. Support GPIO and UART output, plug and play, can be flexibly applied to different intelligent scenes and terminal products.

Datasheet

Features

Plug and play, easy assembly method
Sensing distance up to 100m
Multi-level intelligent parameterization to meet the needs of scene changes
Mobile debugging and configuration tools
Configurable detection distance (10-100m freely adjustable)
Wide detection angle covering up to 3 lanes of traffic
24GHz ISM band, FCC and CE spectrum regulation certifiable
The Ultimate Cost-Effective Choice

Applications

HLK-LD2451 vehicle sensing module can detect and recognize vehicles close to or far away from the vehicle, supports multi-level parameterization, and can be widely used in various intelligent products and terminal products, commonly used types are as follows
Highway intersection Installed at highway intersections, it senses the direction of vehicles traveling on the highway as close or far away, speed, distance, etc.
Non-motorized road
Detecting the blind spot in the rear field of vision, avoiding a car accident caused by a vehicle approaching from behind and changing lanes suddenly
Motorway Detecting distant vehicles behind, assisting the driver to determine the trajectory of the vehicle behind them
Smart Scene Sensing the approach of vehicles, automatic control of road gates, garage doors and other scenes automatically opened or closed

Package Includes

1x Hi-Link HLK-LD2451 24GHz FMCW Millimeter Wave Radar Module | 100m Vehicle Speed, Distance & Motion Detection Sensor with UART/GPIO
