Stepper Motor HAT (B) Alternative Solution Of Stepper Motor HAT, Drives Two Stepper Motors, Up To 1/32 Microstepping For 3D Printer, Sculpturing machine, Mechanical arm...
Features
- Raspberry Pi connectivity, compatible with Raspberry Pi Zero/Zero W/Zero WH/2B/3B/3B+
- Onboard dual DRV8825 motor controller IC with built-in microstepping indexer, easy-to-drive two stepper motors
- 6 available microstepping modes, configured with the DIP switches: full-step, half-step, 1/4-step, 1/8-step, 1/16-step, and 1/32-step
- Adjustable motor drive current via potentiometer, maximum 2.5A current output
- Integrates 5V regulator, allows providing power to Raspberry Pi
- Onboard multi-connector options for stepper motors in different specifications
Resources
Specifications
- Motor controller: HR8825
- Motor drive voltage: 8.2V~28V
- Motor drive current: 2.5A
- Dimension: 65mm × 56mm
- Mounting hole size: 3.0mm


On-Board Peripherals

- Raspberry Pi GPIO interface
- Motor interface
- MP1482 power chip
- HR8825 motor driver chip
- External power supply interface
- Motor power switch
- DIP switch
- Potentiometer
Package Includes
- Stepper Motor HAT (B) x1
- RPi screws pack (2pcs) x1
- Aluminum heatsink x1
