Seeed Studio reServer Industrial J501-Carrier board for Jetson AGX Orin

The reServer Industrial J501 is a powerful carrier board that compatible with NVIDIA Jetson AGX Orin 32GB/64GB modules. It features rich data ports and extension interfaces, completely unleashes the full performance of the AGX Orin module up to 275 TOPS AI performance. The carrier board supports adding GMSL extension to connect up to 8 GMSL cameras, that can be your perfect choice to develop vision AI and autonomous machine with diverse applications.

Resource

Features

Multi-sensors supported: 10GbE, PCIe, DP, GMSL, MIPI CSI-2, USB 3.2
Expand local storage with 2x SATA HDD/SSD
Hybrid connectivity: support 4G/5G, LoRaWAN, Series Wireless
Support JetPack 6.0
Power consumption within 15-60 watts

Specifications

Ethernet: 1x LAN0 RJ45 GbE (10/100/1000Mbps), 1x LAN RJ45 GbE PoE(PSE 802.3 af 15 W, 10/100/1000Mbps)
USB : 3x USB3.1, 1x USB3.1 Type C(Host mode), 1x USB2.0 Type C(Device mode)
DI/DO: 4x DI,4x DO,3x GND_DI,2x GND_DO,1x GND_ISO,1x CAN 1x RS232/RS422/RS485
Display: 1x HDMI 2.1 Type A 7680x4320
SATA: 2x SATA III 6.0Gbps at 30 Hz
SIM: 1x Nano SIM card slot
Button: Reset Button, Recovery Button

Expansion

Mini PCIE: 1x Mini PCIe for LoRaWAN®/4G/Series Wireless (Module not included)
M.2 Key B: 1x M.2 Key B (3042/3052) support 4G/5G (Module not included)
M.2 Key E: 1x M.2 Key E
M.2 Key M: 1x M.2 Key M (PCIE 4.0)
Fan: 1x Fan connectors (5V PWM)
TPM: 1x TPM 2.0 connector (Module not included)
RTC: 1x RTC socket (CR1220 included), 1x RTC 2-pin
Camera: 2x Expansion connector (8lanes for each connector)
PCIE: 1x PCIE

Power Supply: DC 12V-36V Terminal block 2 pin (included 24V/5A Power Adapter)
Dimensions (W x D): 176 x 163mm (Module not included)
Operating Temerature: -20~60℃
Weight: 225g (Module not included)

Package Includes

1x reServer Industrial J501 Carrier Board for Jetson AGX Orin
1x Power Adapter AC Power Brick 120W (Power cable not included)
1x Terminal Connector 20pin
1x 2-Pin Terminal Block Power Connector x1
