LILYGO T-Display-S3 AMOLED With 1.91inch AMOLED Screen Display Module - Solder Version (H634)

LILYGO T-Display-S3 AMOLED With 1.91inch AMOLED Screen Display Module - Solder Version (H634)

This is a LILYGO T-Display-S3 AMOLED With 1.91inch AMOLED Screen Display Module - Solder Version. The T-Display-S3 AMOLED Comes With 1.91inch AMOLED Screen and ESP32-S3R8 Dual-core LX7 microprocessor. Using SPI interface, it is compatible with any microcontroller with SPI capability.

User Manual / Datasheet / Example Codes Etc.

Note : This LILYGO T-Display-S3 AMOLED Module Comes With Solderd Pin Headers.

Specifications

• MCU : ESP32-S3R8 Dual-core LX7 microprocessor
• Wireless Connectivity : 2.4 GHz Wi-Fi & Bluetooth5 (LE)
• Development : Arduino, PlatformIO-IDE, Micropython
• Flash  : 6MB
• PSRAM : 8MB
• Bat Voltage Detection : IO04
• Onboard functions : Boot (IO00) + Reset + IO21 Button
• Resolution : 240 X RGB X 536(H)
• Interface : QSPI
• Active Area : 19.8*44.22mm
• Driver IC : RM67162
• Viewing Angle : IPS Full View Angle

1.91 inch RM67162 IPS AMOLED:

• Resolution : 240 X RGB X 536(H)
• Interface : QSPI
• Active Area : 19.8*44.22mm
• Driver IC : RM67162
• Viewing Angle : IPS Full View Angle
