TYCO LVR125 Resettable Fuse - PPTC 1.25A 1250mA 240VAC 12.5A Imax

TYCO LVR125 Resettable Fuse - PPTC 1.25A 1250mA 240VAC 12.5A Imax
TYCO LVR125 Resettable Fuse - PPTC 1.25A 1250mA 240VAC 12.5A Imax
₹​18.9
₹​16.0 + 18% GST
All Inclusive, Shipping Calculated at Checkout

B2B GST Credit Available

LVR devices help protect electric motors and transformers used in commercial and home appliances from damage caused by mechanical overloads, overheating, stall, lost neutral and other potentially harmful conditions.

LVR series are suitable for line-voltage applications up to a continuous operating voltage of 240VAC.


Features

  • Current ratings from 12.5A
  • Line voltage rating of 240VAC
  • Fast time-to-trip
  • Low resistance
  • Lead Size (AWG) : 0.51mm(24)


Specifications

Hold Current (A)1.25
Trip Current (A)

2.5

Minimum Resistance (Rmin) in Ohms0.165
Maximum Resistance (R1max) in Ohms0.440
Resistance (Max) in Ohms0.253
Maximum Time to Trip (Sec)23
Maximum Interrupt Current (A)12.5
Maximum Interrupt Voltage (VAC)265
Typical Power Dissipation (W)3.3


Resources

Technical Datasheet pdf_icon.png (50×50)


Applications

  • Electromagnetic loads
  • Game machines
  • Industrial controls
  • Lighting ballast
  • Loudspeakers
  • PolySwitch Resettable Devices
  • Line-Voltage-Rated Devices
  • Medical equipment
  • Motors, fans and blowers
  • POS equipment
  • Satellite video receivers
