MCP6002-E/P 1 MHz, Low-Power Op Amp DIP-8

MCP6002-E/P 1 MHz, Low-Power Op Amp  DIP-8
MCP6002-E/P 1 MHz, Low-Power Op Amp DIP-8
₹​57.8
₹​49.0 + 18% GST
All Inclusive, Shipping Calculated at Checkout

B2B GST Credit Available

The Microchip Technology Inc. MCP6001/2/4 family of operational amplifiers (op amps) is specifically designed for general purpose applications. This family has a 1 MHz Gain Bandwidth Product (GBWP) and 90° phase margin (typical). It also maintains a 45° phase margin (typical) with a 500 pF capacitive load. This family operates from a single-supply voltage as low as 1.8V, while drawing 100 µA (typical) quiescent current. Additionally, the MCP6001/2/4 supports rail-to-rail input and output swing, with a Common-mode input voltage range of VDD + 300 mV to VSS – 300 mV. This family of op amps is designed with Microchip’s advanced CMOS process.


Features

  • Gain Bandwidth Product: 1 MHz (typical)
  • Rail-to-Rail Input/Output
  • Supply Voltage: 1.8V to 6.0V
  • Supply Current: IQ = 100 µA (typical)
  • Phase Margin: 90° (typical)


Resources

Technical Datasheet pdf_icon.png (50×50)


Applications

  • Automotive
  • Portable Equipment
  • Photodiode Amplifier
  • Analog Filters
  • Notebooks and PDAs
  • Battery-Powered Systems
