ROCK5 MODEL B 4GB RK3588 64bit octa core ARM based SBC

RADXA´s latest generation SBC based on the just released Rockchip RK3588 in the new standard form factor. Leading edge SOC technology (8nm manufacturing process) combined with a packed feature set and highest  SBC development skills will define new standards in the global SBC market. They are completed with competitive pricing and allows this SBC to open new market segments.

Specifications

RK3588 64bit octa core processor

• Quad Core A76 2.4GHz + Quad Core A55 1.8GHz

GPU

• Mali G610MP4 GPU (up to 5 channel 4k UI)
• 8K 10bit decoder, 8K encoder


NPU

• 6T NPU

Memory LPDDR4

• LPDDR4x with 4, 8 or 16GB

SPI Flash

• 32MB SPI flash soldered

Wifi/BT

• WiFi 6E and BT5.2 support via opt. WiFi module

Micro SD card

• uSD slot supports up to 128G uSD card

M.2 Interfaces

• M.2 connector M key (bottom) for NVMe with PCIe 3.0 x4 lanes
• M.2 connector E key (top) for connectivity with PCIe 2.0 x1/SDIO/UART, WiFi6 cards supported


Display HDMI

• Triple display support (with HDR)
• 2x HDMI 2.1 up to 8k@60FPS
• 1x USB-C with DP up to 8K@30FPS
• HDMI in with up to 4K@60FPS
• 1x MIPI DSI
