Radxa CM5 4GB Ram + 32GB eMMC Compute Module - Based On Rockchip RK3588S2 - No Wireless - RM120‑D4E32R26
The Radxa CM5 is a high-performance compute module based on the Rockchip RK3588S2 SoC, which integrates the CPU, GPU, NPU, PMU, LPDDR4X memory, and eMMC storage into a compact 55mm x 40mm form factor. It boasts impressive capabilities not only in terms of computational performance but also in graphics rendering and AI computing. Whether it's high-performance computing or multimedia processing, the Radxa CM5 can handle it smoothly and stably.
Resource
Specifications
- SoC: Rockchip RK3588S
- CPU: Quad Cortex®‑A76 @ 2.2~2.4GHz and a quad Cortex®‑A55 @ 1.8GHz based on Arm® DynamIQ™ configuration
- GPU: Arm Mali™ G610MP4 GPU ‑ OpenGL® ES1.1, ES2.0, and ES3.2 ‑ OpenCL® 1.1, 1.2 and 2.2 ‑ Vulkan® 1.1 and 1.2 ‑ Embedded high performance 2D image acceleration module
- NPU: NPU supporting INT4 / INT8 / INT16 / FP16 / BF16 and TF32 acceleration and computing power is up to 6TOPs
- Memory: 4GB LPDDR4X
- Storage: 32GB eMMC Supports SDMMC interface for data storage and OS booting using SD cards
- Ethernet: 1x Onboard Gigabit Ethernet PHY
- Video Output:
- 1x HDMI TX up to 8K@60hz
- 1x eDP TX up to 4K@60Hz
- 1x DP TX (and USB3.0 Combo) up to 8K@30Hz
- 1x 2-lane MIPI D/C PHY TX
- 1x 4-lane MIPI D/C PHY TX
- Video Input
- 1x 2-lane MIPI DPHY CSI RX
- 1x 4-lane MIPI D/C PHY RX
- USB
- 2 × USB 2.0 HOST Port
- 1 x USB 3.0 HOST Port
- 1 x USB 3.0 OTG / HOST Port
- PCIe: 2 x PCIe2.0 1‑lane, one shared with USB3 and SATA, one shared with SATA
- SATA2: x SATA ports, one shared with USB3 and PCIe2.0, one shared with PCIe2.0
- Connectivity:
- Up to 2x I2S
- Up to 2x PDM
- Up to 2x SPDIF TX
- Up to 10x UART
- Up to 5x SPI
- Up to 3x CAN
- Up to 7x I2C
- Up to 15x PWM
- Connector: 3 x 100 pins B2B connector
- Operating temperature: 0 ～ 50°C
- Software: Debian / Android
- Dimension: 56 mm × 41 mm
Package Includes
- 1x Radxa CM5 4GB Ram + 32GB eMMC Compute Module - Based On Rockchip RK3588S2 - No Wireless - RM120‑D4E32R26
