Radxa ROCK Pi S0 RK3308B 512MB RAM No eMMC WiFi Bluetooth With Header Mini SBC

Radxa ROCK Pi S0 512MB DDR3 RAM No eMMC Single Board Computer - Based On Rockchip RK3308B Processor - Onboard Wi-Fi 4 & Bluetooth 5.0

Radxa ROCK S0 is a Single Board Computer (SBC) in an ultra‑tiny form factor that offers class‑leading performance while leveraging outstanding mechanical compatibility. The Radxa ROCK S0 offers makers, IoT enthusiasts, hobbyists, PC DIY enthusiasts and others a reliable and extremely capable platform for building and tinkering their ideas into reality.

This product comes with 512 MB RAM and wireless connectivity, eMMC is not available in this version.

Resource

• Datasheet
• Overview
• Getting started


Specifications

• SoC: RK3308B
• CPU: Quad‑core Arm® Cortex®‑A35 64‑bit @ 1.0GHz
• RAM: 512MB DDR3
• Storage: No Onboard eMMC &  1 x Micro SD Card Slot
• Wireless: IEEE 802.11b/g/n(WiFi4) wireless Lan with external antenna or onboard antenna support & BT 5.0 with BLE
• USB: 1x USB2.0 OTG via 4-Pin MX 1.25mm connector for Power and Data & 1x USB2.0 HOST via 4-Pin MX 1.25mm connector
• Ethernet: 1x 100M Ethernet RJ45 via 4Pin MX 1.25mm connector
• IO: 40-Pin GPIO Header
• Power: 1x USB2.0 OTG via 4-Pin MX 1.25mm connector for Power and Data
• Form Factor (Dimension): 65mm x 30mm
• Software: Support Debian / Linux

Interfaces
