Name: RP2350 1.43inch AMOLED Display Development Board, 466×466, SPI Interface Round Display, Onboard Accelerometer And Gyroscope Sensor, RTC Chip
Brand: WaveShare Electronics
SKU: 30735
Price: 2285.00 INR
Availability: OutOfStock

RP2350 1.43inch AMOLED Display Development Board, 466×466, SPI Interface Round Display, Onboard Accelerometer And Gyroscope Sensor, RTC Chip

WaveShare Electronics

RP2350 1.43inch AMOLED Display Development Board, 466×466, SPI Interface Round Display, Onboard Accelerometer And Gyroscope Sensor, RTC Chip

Based on 0 reviews. - Write a review

₹2,285.00

₹1,936.44 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 19
B2B GST Credit Available

Price in reward points: 1936

Stock: 0 in Stock
SKU: 30735
Delivery Time
Bulk & B2B RFQ

Buy Now NOTIFY WHEN AVAILABLE

Plan to Buy Later ? Add to Wish List

RP2350 1.43inch AMOLED Display Development Board, 466×466, SPI Interface Round Display, Onboard Accelerometer And Gyroscope Sensor, RTC Chip [Without Case]

This product adopts RP2350 chip with built-in high-capacity Flash memory, onboard 1.43inch AMOLED display, capable of smoothly running GUI applications such as LVGL. Onboard rich peripheral resources such as RTC chip, QMI8658 6-axis IMU, TF card slot, Lithium battery header, etc., and reserved USB, UART, I2C and GPIO pin headers, offering strong expandability. It is suitable for the quick development of the RP2350 HMI applications.

User Manual / Datasheet / Example Codes Etc.

Features

Adopts unique dual-core and dual-architecture design, equipped with dual-core ARM Cortex-M33 processor and dual-core Hazard3 RISC-V processor, flexible clock running up to 150 MHz
Built-in 520KB of SRAM and 16MB of on-chip Flash
Onboard 1.43inch AMOLED display, 466 × 466 resolution, supporting 16.7M color
AMOLED screen display uses an SPI interface, capacitive touch screen uses an I2C interface, supporting interrupt output
Onboard QMI8658 6-axis IMU (3-axis accelerometer and 3-axis gyroscope) for detecting motion gesture, step counting, etc.
Built-in PCF85063 RTC chip, with a reserved SH1.0 battery slot (supporting charging) for RTC functionality implementation
Onboard RST and BOOT side buttons
Onboard 3.7V MX1.25 lithium battery recharge/discharge header
Built-in TF card slot, supports external TF card storage for images or files
Onboard USB Type-C port for power supply, downloading and debugging, making development more convenient
Lead out the UART and I2C SH1.0 4PIN interface, and reserve a 2×14PIN 1.27mm pitch interface
USB1.1 host and device support
Low-power sleep and dormant modes
Temperature sensor
Accurate clock and timer on-chip
On-chip accelerated floating-point library

Specifications

Display Size: 1.43 inch
Display Panel: AMOLED
Resolution: 466×466
Display Colors: 16.7M
Brightness: 350 cd/㎡
Contrast Ratio: 60000:1
Communication Interface: SPI
Driver IC: C05300
Touch: Supported
Touch IC: FT6146

Package Includes

RP2350-Touch-AMOLED-1.43 x1
SH1.0 4PIN cable ~100mm x2

Interface definition

adapting multiple GPIO interfaces, more convenient for development, offers strong flexibility

What's On Board

Dimensions
