RTC WatchDog HAT for Raspberry Pi, Auto Reset, High Precision RTC
₹​1,437.24
₹​1,218.00 + 18% GST
All Inclusive, Shipping Calculated at Checkout
Assured Cashback of ₹ 12
B2B GST Credit Available

Features

  • MAX705 monitoring circuit with auto reset function.
  • Incorporates DS3231SN high precision RTC chip, with backup battery holder.
  • Reset pin selection for switching watchdog.
  • Indicator for watchdog output warning.


Resources

User Guide


Onboard Peripherals



  1. USB Type-C power input
  2. MAX705 watchdog
  3. Watchdog output enable
    1: enabled
    0: disabled
  4. CR1220 RTC battery holder
    RTC power supply, supports CR1220 button cell
  5. Watchdog output warning
    lights up if the watchdog is overflow
  1. Raspberry Pi 40PIN GPIO header
  2. RTC chip
    DS3231 high precision RTC chip
  3. Watchdog reset pin selection
  4. Control interface
    for use with other host boards
Auto Reset Monitoring

MAX705 Monitoring Circuit With Auto Reset Function

High Precision RTC

Incorporates DS3231SN High Precision RTC Chip, With Backup Battery Holder
