The SIM800C is a Quad-Band GSM/GPRS module in a LCC type which supports GPRS up to 85.6kbps data transfer. It has strong extension capability with abundant interfaces including UART, USB2.0, GPIO etc. The module provides much flexibility and ease of integration for customer's applications.

Datasheet

General Features

• Frequency Bands: 850/900/1800/1900MHz
• GPRS multi-slot class: 12/10
• Dimensions: 17.6*15.7*2.3mm
• Supply voltage: 3.4 ~ 4.4V
• Operation temperature:-40℃ ~85℃
• Compliant GSM phase 2/2+: Class 4 (2W @ 850/900MHz)
• Compliant GSM phase 2/2+: Class 1 (1W @ 1800/1900MHz)
• Control via AT commands (3GPP TS 27.007, 27.005 & SIMCom enhanced AT Commands)
• Low power consumption
• GPRS mobile station class B

SIM800C Advantages

• Small size quad-band GSM/GPRS module
• LCC form factor, easy for solder
• Abundant software functions: DTMF, MMS, MUX
• Low Power consumption
• Embedded TCP/UDP protocols

Interfaces

• Analog audio interface
• UART
• (U)SIM card(1.8V/3V )
• RTC
• ADC
• GPIO
• Antenna: GSM/BT*
