Sipeed MAIX R6+1 Microphone Array
₹​1,764.10
₹​1,495.00 + 18% GST
All Inclusive, Shipping Calculated at Checkout
Assured Cashback of ₹ 15
B2B GST Credit Available

Sipeed 6+1 Microphone Arra is a 6 microphone expansion board for Maix AI development boards designed for AI and voice applications.

Including 6+1 digital microphones, 12 three-color LEDs, it supports sound localization, beam forming, speech recognition etc.


SPECIFICATION
6 MEMS microphones : MSM261S4030H0Sound Pressure Level : 140 dB SPL
Sensitivity : -26(dB,dBFS @1kHz 1Pa)
Signal to noise ratio : 57 dB (20kHz bandwidth,A-weighted)
THD<1% (100dB SPL @1kHz S=Nom,Rload>2k ) Clock frequency :
1.0-4.0Mhz(normal mode)
150-800khz(low power mode)
12 SK9822 LEDsViewing angle : 120 degree Synchronous of two-lane
Choose postive output or negative output RGB tri-color L ED out, 8 Bit(256level) color Set, 5Bit (32 level) brightness adjustment
Current 20ma per color, 60mA total at full brigtness
ELECTRICAL SPEC
Supply voltage of external power supply3.3V ±0.2V
Supply current of external power supply>750mA(Full brightness)
Temperature rise<30K
Range of working temperature-30℃ ~ 85℃

6+1 Mic dimension
