SX1302 868M LoRaWAN Gateway Module, EU868 Band.
This is a communication HAT for Raspberry Pi with LoRaWAN protocol support, which incorporates the core LoRa gateway module SX1302 868M LoRaWAN Gateway. It has lots of advantages including long-range transmission, concurrent communication, large capacity node, and high receiving sensitivity. There are L76B GNSS module and Mini-PCIe socket on the baseboard for easy integration, along with our rich development resources, you can attach it to Raspberry Pi and build the LoRa network fast.
User Manaual / Datasheet / Example Codes Etc.
Features
- Standard Raspberry Pi 40PIN GPIO extension header, supports Raspberry Pi series boards
- Incorporate L76B module with GPS/BD support, Gateway module for providing accurate clock and location info
- Comes with development resources and manual (example in C)
- Integrates Semtech SX1302 normal band and SX1250 radio RF frond-end chip, EU868 band
- Onboard PA and LNA, features 26dBm emit power and -141dBm high sensitivity receiving gain
- 10 x signal channel supports multiple nodes concurrent communication and FEC (Forward Error Correction) algorithm
- Supports SF5~SF12 spreading factor, 19Kbps MAX (SF5/BW125KHz) data rate
- Utilizing SPI communication protocol and standard Mini-PCIe socket, for easy integration into sorts of embedded systems
Specifications
- Power supply : 5V
- Frequency range : EU868 (863-870MHz)
- Modulation : LoRa/(G)FSK
- Emit power : > 26dBm@5V
- Receiving sensitivity : -141dBm@125KHz/SF12, -121dBm@125KHz/SF5
- Overall power consumption : emitting: 652mA@5V receiving: 38mA@5V sleep: 6mA@5V
- Communication bus : SPI, I2C
- External connector : Mini-PCIe
- Operating temperature : -40~85℃
- Dimensions : 50.95 x 30mm
Performance-Upgraded SX1302 Chip
Lower Power Consumption, Fast Data Rate, Longer Distance
Multiple Channels Smooth Communication
A Better Solution For Concurrent High Throughput Situation
FEC Forward Error Correction Algorithm
The New Generation LoRa Spread Spectrum Technology, Higher Anti-Interference Performance, Longer Communication Distance
Dimensions
