TX868-JK-11 868MHz 3dBi Omnidirectional Lora Antenna

TX868-JK-11 868MHz 3dBi Omnidirectional Lora Antenna - SMA-J Interface

TX868-JK-11 is a bendable rubber rod antenna in the 868MHz frequency band. The overall height of the antenna is about 110mm, with SMA-J interface (SMA internal thread and needle), suitable for broadband communication systems in the 868MHz frequency band, wireless hotspot coverage, and mobile terminal devices; Such as routers AP、 Radio station, network card, etc.

Specifications

• Part Number: TX868-JK-11
• Frequency: 848MHz-868MHz
• Antenna Gain: 3dBi
• Radiation type: Omnidirectional
• Connector Type: SMA-J
• Antenna Color: Black
• Overall Length: 110mm
• Polarization Linear: Vertical
• Nominal Impedance: 50Ω
• Power Capacity: 10W
• S.W.R.: <1.5
• Operation Temperature: -40℃～+80℃
• Storage Temperature: -40℃～+85℃

Package Includes

• 1x TX868-JK-11 868MHz 3dBi Omnidirectional Lora Antenna
