UPS HAT (E) for Raspberry Pi, Supports 4× 21700 Li batteries (NOT included), Bi-Directional Fast charging, 5V 6A Output, Pogo Pins Connector, Raspberry Pi UPS

The UPS HAT (E) is an uninterruptible power supply (UPS) expansion board specially designed for the Raspberry Pi series. Onboard battery fuel gauge IC, fast charging chip and high-power buck chip to realize higher power input and output. Supports monitoring the operating state of the HAT via the I2C interface.

User Manual / Datasheet / Example Codes Etc.

Features

Adopts pogo pins connector design, compatible with Raspberry Pi 5/4B/3B+.
Onboard Type-C port with bi-directional fast charging, supports multiple charging input / output protocols such as PD3.0, up to 40W charging power.
Onboard battery fuel gauge IC for reading battery voltage, current, power, remaining capacity and other parameters.
Supports I2C bus communication for monitoring the operating status of Type-C port and batteries in real time.
Supports 4× 21700 Li batteries (NOT included), larger capacity and longer battery life.
Onboard high-power buck chip for stable 5V 6A power output.
Onboard MCU management, supports detecting power connection and booting the Raspberry Pi.
Supports displaying battery level on the system, easy to check the operating state of the HAT.
Comes with online development resources and manuals.

Specifications

OUTPUT VOLTAGE: 5V
CONTROL BUS: I2C
RECHARGING BATTERY: PD2.0/PD3.0 bidirectional input/output protocol, support up to 40W
OUTPUT POWER: 5V 6A
BATTERY SPECIFICATION: 21700 RECHARGEABLE BATTERIES 3.6V
CURRENT CAPACITY: 5000mAh (Standard)
DIMENSIONS: 56mm × 88mm
MOUNTING HOLE SIZE: 3.0mm

Package Includes

1x UPS HAT (E)
1x Acrylic protection panel
1x Screws pack

Supports 21700 large capacity Li battery, Longer Battery Life

Onboard warning indicators, easy to check if the battery is connected correctly

Onboard USB interfaces

Adopts USB Type-C interface, supports multiple input/output protocols. Supports 5V, 9V, 12V, 15V, 20V input voltage, up to 40W charging power. Onboard USB Type-A interface for 5V power output, more convenient for powering other boards

Pogo pins connector

Powering the Raspberry Pi via pogo pins, without using any GPIO resource,compatible with Raspberry Pi 5 / 4B / 3B+, etc.

Real time monitoring

monitoring the Type-C port and batteries voltage, current, power, and remaining capacity via I2C

Dimensions
