Industrial USB TO 4CH TTL Converter, USB To UART, Multi Protection & Systems Support

Industrial USB TO 4CH TTL Converter, USB To UART, Multi Protection & Systems Support
Industrial USB TO 4CH TTL Converter, USB To UART, Multi Protection & Systems Support
Industrial USB TO 4CH TTL Converter, USB To UART, Multi Protection & Systems Support
Industrial USB TO 4CH TTL Converter, USB To UART, Multi Protection & Systems Support
WaveShare Electronics
Industrial USB TO 4CH TTL Converter, USB To UART, Multi Protection & Systems Support
₹​1,425.00
₹​1,207.63 + 18% GST
All Inclusive, Shipping Calculated at Checkout
Assured Cashback of ₹ 12
B2B GST Credit Available
Price in reward points: 1208

Features

  • Extending USB to 4CH TTL (UART) with hardware flow control, allows concurrent and independent communication for each channel
  • Onboard resettable fuse and protection diodes, ensures the current/voltage stable outputs, provides over-current/over-voltage proof, improves shock resistance
  • Onboard IO protection circuit for surge suppress and ESD protection, safe and stable communication
  • Onboard TTL serial port 3.3V and 5V voltage level switch, allows selecting TTL level
  • Aluminium alloy enclosure with oxidation dull-polish surface, CNC process opening, solid and durable, well-crafted
  • Quality USB-B connector, and IDC connector with fool-proof design

Resources : http://www.waveshare.com/wiki/USB_TO_4CH_TTL


Specifications

  • Working voltage: 5V
  • Working current: 32mA
  • Serial Baud rate: 1200bps ~ 460800bps
  • TTL voltage: 3.3V / 5V (configurable)
  • Working temperature: -40°C ~ 85°C
  • Supported OS: Mac OS, Linux, Windows 11/10/8.1/8/7, Android
