WaveShare Electronics
₹2,075.42 + 18% GST
B2B GST Credit Available
FT232RNL USB TO RS232/485/422/TTL Interface Converter
1 Pin - Male to Female Jumper Wire - 12 Inch/30.5cm - Pack of 100 PCS Description : These wires are commonly used for prototy..
₹454.30
Ex Gst ₹385.00
250 Meter Multicolor Circuit Wrapping Wire - PVC Insulated -Tinned Copper Wire - 30AWG Wrapping Wire is suitable for Flexible and insulation wrap..
₹449.00
Ex Gst ₹380.51
F-F Jumper Wire - Set of 40 - 2.54mm - 20cm LengthSet of 40 jumper wires with female connector at both ends. Allow you to easily prototype with ..
₹57.82
Ex Gst ₹49.00
F-M Jumper Wire - 20cm Length - 2.54mm - Set of 40Set of 40 jumper wires with female connector at one end and male connector on other. Allo..
₹57.82
Ex Gst ₹49.00
Male to Male Jumper Wires - 1 Pin - Set of 65 Wires - Mix colors - Mix LengthThis is a set of 65 pcs male-to-male high-quality jumper wires cables..
₹93.00
Ex Gst ₹78.81
Male to Male Jumper Wires - 20cm Length - 2.54mm - Set of 40 Set of 40 jumper wires with male connector at both ends. Allow you to..
₹57.82
Ex Gst ₹49.00
2 Pin Shunt - 2.54mm Pitch - Jumper Cap - Yellow ColorPackage Includes : 10x Yellow Jumper Cap 2.54mm
Position
2 Pin
..
₹29.50
Ex Gst ₹25.00
Duracell CR2032 3V Lithium Coin Cell BatteryThe Duracell CR2032 3V Lithium Coin Cell Battery is a reliable and widely used power source for various el..
₹40.00
Ex Gst ₹33.90
400 Tie Points - Solderless BreadboardHigh Quality breadboard with power lanes and printed top face for easy prototyping.Specifications..
₹49.00
Ex Gst ₹41.53
USB Type A to B Male Cable - 30 CM Cable Length - Specially Design for ArduinoThe USB Type A to B Male Cable – 30 CM Cable Length is specifically desi..
₹35.00
Ex Gst ₹29.66This product qualifies for Free Surface Shipping !
All orders with value above 1999+GST are eligible for free delivery in Surface mode. (Not applicable for B2B offline orders)
₹2,449.00
All Inclusive, Shipping Calculated at Checkout
Assured Cashback of ₹ 21
B2B GST Credit Available
Price in reward points: 2075
- Stock: 10 in Stock
- SKU: 23996
- Delivery Time
- Bulk & B2B RFQ
USB TO RS232/485/422/TTL, an industrial-grade isolated converter, adopts the original FT232RNL, built-in protection circuits including power isolation, ADI magnetical isolation and TVS, and with aluminum alloy shell design. USB TO RS232/485/422/TTL is easy to operate and features an automatic transmission and reception conversion with zero delays. Also, it has the characteristics of fast communication speed, stability, reliability, safety, etc., and can be applied to various industrial control device or applications with high communication requirements.
Features
- Adopt original FT232RNL chip, fast communicating, stable and reliable, better compatibility.
- Supports multiple communication interface conversion: USB to RS232, USB to RS485, USB to RS422, USB to TTL.
- Onboard unibody power supply isolation, provides stable isolated voltage and needs no extra power supply for the isolated terminal.
- Onboard unibody digital isolation, allows signal isolation, high reliability, strong anti-interference, and low power consumption.
- Onboard TVS (Transient Voltage Suppressor), effectively suppresses surge voltage and transient spike voltage in the circuit, lightning proof & ESD protection.
- Onboard self-recovery fuse and protection diodes, ensure the current/voltage stable outputs, provides over-current/over-voltage proof, and improve shock resistance.
- Fully automatic transceiver circuit with no delay, ensures the USB port communicates with different interfaces fastly and stably, without interfering with each other.
- Onboard TTL serial 3.3V/5V voltage translator, config the TTL level via a switch.
- 3 LEDs for indicating the power and transceiver status.
- High-quality USB-B and RS232 connectors, smoothly plug/pull.
- Industrial grade metal case supports wall-mount and rail-mount installations, solid and beautiful, easy to install.
Resources
User Guide
Pinouts
