USR-N720-ETH+4G High Performance Edge IoT Gateway - Based on RISC-V Processor - 2 RS485 + 1 Ethernet Interface - Support Modbus TCP/ RTU Protocol
USR-N720 is a high-performance IoT gateway supporting edge computing, edge data acquisition, protocol conversion and data encryption. This product adopts the processor with data encryption and the main frequency is up to 600MHz, designed for industrial-grade stability. It supports communication via TCP(S)/MQTT(S) protocols and facilitates bidirectional interaction with Modbus RTU over TCP and custom JSON protocol data. The USR-N720 can be widely applied in various industrial intelligent solutions, including smart breeding, smart factories, smart agriculture, and smart grid.
Key Features
- Multiple Interface: Ethernet+2*RS485+4G
- Powerful Edge Computing Capabilities: 1000 points + data acquisition + analysis
- Data Encryption: TCP+SSL, MQTT+SSL
- Protocol Conversion: Modbus to MQTT + Json, DL645 to MQTT + Json
- Rich Communication Protocol: MQTT/TCP
- SD Card for Data Storage: To ensure data integrity
Resources
User Manual / Datasheet / Example Codes Etc.
Note: 4G antenna is not included with the USR-N720-ETH+4G High Performance Edge IoT Gateway. A compatible external 4G antenna must be purchased separately for cellular connectivity : Link
Specifications
- Model: USR-N720-ETH+4G
- Processor: RISC-V core
- Frequency: Up to 600MHZ
- Power Supply: DC 9-36V, 2-pin terminal blocks
- Ethernet: 1 x RJ45 ( Rate 10 /100 Mbps, auto MDI/MDX)
- Serial Port: 2 x RS485, 7-pin terminal blocks
- Network protocol: IP,TCP,MQTT,SSL/TLS,ICMP,ARP,DNS,NTP,DHCP, IPv4
- Work Mode: TCP Server/TCP client 2 * independent TCP connection supported
- Edge acquisition protocol: Modbus RTU, DLT645/2007
- Data reporting format: Json, Modbus TCP
- Data points: Up to 1000 points
- MQTT
- Standard MQTT protocol
- Easy access to mainstream paltform: Things board, AWS, Azure, etc.
- 2 * independent MQTT connection supported
- Installation: DIN rail or wall mounting
- Operating Temperature: -40～85℃
- Storage Temperature: -40~105℃
Applications
- Smart Manufacturing
- Smart Building
- Smart Animal Husbandry
- Intelligent Agriculture
- Energy Monitoring
Package Includes
- 1x USR-N720-ETH+4G
- 1x Power Adapter
- 1x Power Adapter Cable
- 1x Wall Mount Kit
Dimensions and Peripherals
