USR-TCP232-E2 Dual Serial UART TTL to Ethernet Converter Module
USR-TCP232-E2 is a dual serial UART to Ethernet TCP/IP module. It adopts Cortex-M7 solution,which has a main frequency up to 400MHz, powerful performance, fast transmission speed, and high reliability. Equipped with a deeply optimized TCP/IP stack, built in hardware and software watchdog and a variety of keepalive mechanisms,USR-TCP232-E2 keeps online all the time. It supports TCP Client, TCP Server, UDP Client, UDP Server and HTTPD Client working modes, achieves data transparent transmission via simple
Resource
Features
- Support TCP server, TCP client and UDP, HTTP operating modes
- Support RS-485 enable pin of an external RS-485 transceiver
- Support flow control CTS/RTS, XON/XOFF
- Auto-MDI/MDIX, RJ45 port with 10/100Mbps
- Flexible data packet condition for the serial interface
- Support DHCP to configure the IP address and other network configuration parameters
- Support DNS for remote server domain name lookup
- Support Modbus RTU to Modbus TCP/UDP
- Support Modbus over TCP/UDP
- Support three configuration methods: serial AT command, PC software, and web page
- Support local firmware upgrade by PC software
- Support “Keep-Alive” to guarantee TCP connection
- Support user password authorization for security
- Industrial temperature range (-40℃~+85℃)
Applications
- Industrial data transmission, industrial automation
- security and protection monitoring, public security
- Smart home, power control, environmental monitoring, intelligent agriculture
- Door check on work attendance system, POS system, rice selling system
- Building automation system, power monitoring, self-service banking system, telecom machine room monitoring
Data Submitted to Web Server Directly
Work Mode of UART over Ethernet Modules USR-TCP232-E2
TCP Client Mode
TCP Server Mode
UDP Mode
Application of TTL to Ethernet Modules USR-TCP232-E2
Remotely manage multiple serial device
Use network to extend serial communication distance
Multiple PC to remotely manage serial device
