WIZnet W6100-EVB-Pico2 RP2350 & W6100 Based Evaluation Board

WIZnet W6100-EVB-Pico2 RP2350 & W6100 Based Evaluation Board
WIZnet W6100-EVB-Pico2 RP2350 & W6100 Based Evaluation Board
WIZnet W6100-EVB-Pico2 RP2350 & W6100 Based Evaluation Board
WIZnet W6100-EVB-Pico2 RP2350 & W6100 Based Evaluation Board
WIZnet W6100-EVB-Pico2 RP2350 & W6100 Based Evaluation Board
WIZnet W6100-EVB-Pico2 RP2350 & W6100 Based Evaluation Board
WIZNET
WIZnet W6100-EVB-Pico2 RP2350 & W6100 Based Evaluation Board
₹​1,298.00
₹​1,100.00 + 18% GST
All Inclusive, Shipping Calculated at Checkout
Assured Cashback of ₹ 11
B2B GST Credit Available
Price in reward points: 1100

WIZnet W6100-EVB-Pico2 RP2350 & W6100 Based Evaluation Board

W6100-EVB-Pico2 is a microcontroller evaluation board based on the Raspberry Pi RP2350 and fully hardwired TCP/IP controller W6100 – and basically works the same as Raspberry Pi Pico board but with additional Ethernet via W6100.

  • Raspberry Pi Pico2 Clone
  • Ethernet (W6100 Hardwired TCP/IP CHIP)


Resource


Features

  • RP2350 Microcontroller with Integrated 16Mbit Flash
    • Symmetric dual Arm Cortex-M33 cores at up to 150MHz
    • 520kByte multi-bank high performance SRAM
    • External Quad-SPI Flash with eXecute In Place (XIP) capabilities
    • Enhanced performance full-crossbar bus fabric
    • Up to 48 multi-function General Purpose IO (8 can be used for ADC on RP2350-B)
    • 1.8-5.0V IO Voltage
  • Security Features
    • One Time Programmable (OTP) Memory: Used for boot configuration and secure key storage.
    • Secure Boot: Ensures that only authenticated software can run on the device, utilizing OTP for key verification.
    • Arm TrustZone Technology: Provides hardware isolation between secure and non-secure software, enhancing security for critical applications.
  • Analog and Digital Peripherals
    • 12-bit 500ksps Analogue to Digital Converter (ADC)
    • 2 × UART, 2 × I2C, 2 × SPI, 16 × PWM channels
    • 1 × Timer with 4 alarms, 1 × Real Time Counter
    • 3 × Programmable IO (PIO) blocks, 12 state machines total
    • Flexible, user-programmable high-speed IO
    • Can emulate interfaces such as SD Card and VGA
  • W6100 Ethernet Controller
    • Supports Hardwired Internet Protocols: TCP, UDP, IPv6, IPv4, ICMPv6, ICMPv4, IGMP, MLDv1, ARP, PPPoE
    • Supports 8 independent SOCKETs simultaneously with 32KB memory
    • Internal 16 Kbytes Memory for TX/ RX Buffers
    • SPI Interface
  • Connectivity
    • C-Type USB port for power and data (and for reprogramming the Flash)
    • 40 pin 21x51 'DIP' style 1mm thick PCB with 0.1" through-hole pins also with edge castellations
    • 3-pin ARM Serial Wire Debug (SWD) port
  • Networking
    • 10 / 100 Ethernet PHY embedded
    • Supports Auto Negotiation
    • Full / Half Duplex
    • 10 / 100 Based
    • Built-in RJ45(RB1-125BAG1A)
  • Power Supply: Built-in Switch-mode DC-DC converter (replacing LDO for enhanced power efficiency)


Pin-out
