WCH-DAPLink-R0-2v0 Emulation Debugger Module with SWD/JTAG Interface

WCH

WCH-DAPLink-R0-2v0 Emulation Debugger Module with SWD/JTAG Interface

Based on 0 reviews. - Write a review

₹649.00

₹550.00 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 5
B2B GST Credit Available

Price in reward points: 550

Stock: 0 in Stock
SKU: 05549
Delivery Time
Bulk & B2B RFQ

Buy Now NOTIFY WHEN AVAILABLE

Plan to Buy Later ? Add to Wish List

WCH-DAPLink-R0-2v0 Emulator MCU Programmer Online Debugging for ARM Chips with SWD/JTAG Interface

The WCH-DAPLink module can be used for online debugging and downloading for ARM chips with SWD/JTAG interface. It supports two modes, i.e. ARM mode-WINUSB device and ARM mode-HID device. Through its USB2.0 full-speed interface, it can be connected to a computer host. It is plug and play. Connected to target chips by the debugging interface, it can be used for debugging and programming.

Datasheet

Features

Two 3.3V/5V power supply outputs are supported
Supports USB to TTL serial port function
Supports downloading and debugging for ARM kernel MCU with SWD/JTAG interface
Supports automatic firmware detection and upgrade
3.3V/5V output power supply is controllable
Automatic power-off protection
Red and blue LED indicator lights make it easy to check the working status
Supports a host computer to switch working mode via one key

Specifications

Default parameters of serial port:

Data bit : 8
Stop bit : 1
Check digit : None
Flow Control : None
Baud rates : 1200, 2400, 4800, 9600, 14400, 19200, 38400, 57600, 115200, 230400, 460800 and 921600bps
