WIN-IO-1AI1AOM IO Module with 10-bit, 1 AI + 1 AO Modbus RTU

WIN-IO-1AI1AOM IO Module with Input Resolution 10-bit, 1 Analog Input and 1 Analog Output and Modbus RTU RS485 interface

The WIN-IO-1AI1AOM IO Module is an advanced industrial control device designed to elevate automation systems with its precise analog input and output capabilities. Featuring a 10-bit resolution, this module ensures high-precision data acquisition for applications that require accurate monitoring and control of analog signals.

The IO modules communicate via RS485. The port can drive distances up to max 700 meters without the use of any repeater (this feature however also depends  on the signal strength of the Modbus Master Device).

The RS485 Digital IO module is sturdy, low power usage and easy to use.

Datasheet

Specifications

• I/O Connectors : 2 Pin 5.08 mm pitch pluggable screw terminals.
• Dimensions : 70 mm L x 110 mm B x 50 mm H
• Power : Input Power – 24 V AC/DC Typical – 12V DC @ 80mA
• Operating Temperature : 0 – 60°C (32 ~ 140°F)
• Storage Temperature : -20 - 70°C (-4 ~ 158°F)
• Storage Humidity : 5 ~ 95 % RH, non – Condensing

AI Inputs

• Channels : 1
• Input Signal : 4 – 20 mA / 0 – 20 mA / 0 – 10 V (jumper selectable)
• Accuracy : ±2% Full scale
• Input Resolution : 10-bit
• Isolation : Optically Isolated
• External Loop : Voltage + 12 VDC min
• AI input impedance : 120 Ohm

AO Outputs

• Channels : 1
• Inputs Resolution : 10 Bit
• Signal Range : 0 – 10V
• Accuracy  : ±2 % of Full scale
• Linearity Error : 0.1 %
• Conversion Time : 20 msec

Additional Features

• Communication port isolated
• Input power reverse polarity safety
• ESD Safety IEC 61000-4-2, ±30KV contact, ±30KV air
• EFT IEC 61000-4-4, 50A (5/50ms)
• 750V isolation.
• CRC Error check.
• No configuration needed on the IO board
• 1 year comprehensive warranty
