XH-M542 TPA3116D2 100W Mono Channel Digital Audio Power Amplifier Board
The TPA3116D2 XH-M542 Single Channel Digital Power Amplifier Board is a newly designed, high-efficiency digital audio amplifier that offers excellent performance and practicality. Built with the advanced TPA3116D2 chip, this board utilizes a high-efficiency Class D amplifier design to deliver up to 100W of clear and powerful mono sound. The BTL (Bridge-Tied Load) bridge circuit enhances overall efficiency, making it ideal for driving subwoofers and large speakers in home audio setups or DIY projects. Designed for easy installation and use, this amplifier board provides reliable and consistent audio quality with minimal distortion and noise. The original core technology of the TPA3116D2 ensures stable operation, making it a versatile and dependable choice for any single-channel amplification needs.
Features
- Strong TPA3116D2 chip is a digital power amplifier chip, with low idle loss characteristics, makes it work well and quickly.
- Onboard, front-facing IC to improve the input sensitivity, high-definition sound quality.
- It can be used for car vehicle computer speaker, family audio and video, and empty square.
- This product has the characteristics of loud sound, the capacitance is large, excellent sound quality.
- There is no solder joint on the back of the circuit board, the chip capacitors and the solder board together, so there is no possibility of short circuit.
Specifications
- Amplifier Chip: TPA3116D2
- Supply voltage: DC12-26V
- Output power: 100W
- Signal to noise ratio: 100db
- Number of channels: mono
- Size: 79*54*16(mm)
- Weight: 53g
Applications
- Subwoofer Amplification
- DIY Audio Projects
- Home Audio Systems
- Car Audio Systems
Package Includes
- 1x XH-M542 TPA3116D2 100W Mono Channel Digital Audio Power Amplifier Board
