XH-M603 Battery Charging Control Module With LED Display

The XH-M603 Charging Control Module is a reliable and versatile solution designed for managing the charging process of 12V to 24V lithium batteries. This control board ensures efficient charging while protecting your battery from overcharging and extending its overall lifespan. Equipped with adjustable voltage settings, the module allows users to customize the charging start and stop points, making it suitable for a variety of battery configurations.

With its intuitive LED indicators and a clear LCD display, the XH-M603 provides real-time monitoring of voltage levels and charging status. The compact design and straightforward interface make it an ideal choice for DIY battery projects, solar energy storage systems, and other battery-powered applications.

Application Fields: 12-24V storage battery. It is applicable to solar cells, new energy batteries, Lead-acid batteries, nickel-cadmium batteries, nickel-metal hydride batteries, lithium-ion batteries, polymer batteries, Car battery, electric car battery

Using Method:

1. Set Starting Voltage: in normal display voltage state, press the button will display start charging voltage; long press for 3s the digital tube will flash; you can start or stop button to set starting up charge voltage value.

2. Set Stop Voltage: in normal display voltage state, press the button will display stoping charge voltage: long press the button for 3s the digital tube will flash; you can start or stop button to set stoping charge voltage value.

3. Factory Reset: in power on state press the start/stop button at the same time, digital tube will display 888;that represents factory reset settings.

Features

Automatic control circuit connection
Automatic charging and power off
Real-time voltage monitor
Autosave setting
ST core chip
LM2596 switch voltage regulator

Specifications

Model: XH-M603
Input Voltage: DC 10-30V
Display Precision: 0.1V
Control Precision: 0.1V
Output Type: direct output
Voltage Tolerance: +/-0.1V
Application Fields: 12-24V storage battery
Size: 82*58*18mm

Package Includes

1x XH-M603 Battery Charging Control Module With LED Display

Wiring Diagram
