1.9inch Segment E-Paper Module, 91 Segments, I2C Bus, Ideal for Temperature and humidity meter, Humidifier, Digital Meter

This display is a Segment Electrophoretic Display Module which can be used in thermometer. The module is integrated circuits including Segment drivers.

User Manual / Datasheet / Example Codes Etc.

Features

White Reflectance above 35%(0 minute)
Contrast Ratio above 9:1(0 minute)
Wide viewing angle
Ultra low power consumption
Reflective mode
Bi-stable display
Commercial temperature range
I2C Interface

Specifications

OPERATING VOLTAGE : 3.3V/5V
GREY SCALE : 2
INTERFACE : I2C
PARTIAL REFRESH TIME : 0.3s
OUTLINE DIMENSIONS : 51 × 34 mm
FULL REFRESH TIME : 2s
DISPLAY SIZE : 41.35 × 28.11 mm
REFRESH POWER : <5mW (typ.)
SEGMENTS : 91
STANDBY CURRENT : <0.01uA (almost none)
DISPLAY COLOR : Black/White
VIEWING ANGLE : >170°

Package Includes

1.9inch Segment e-Paper Module x
6Pin Cable x1

Onboard I2C Control Interface

VCC : Power (3.3V / 5V input)
GND : Ground
SDA : I2C data input
SCL : I2CI clock input
RST : External reset, low active
BUSY : Busy status output pin (high level means busy)

Application Examples

Dimensions
