2-Channel Isolated CAN Bus Expansion HAT For Raspberry Pi, Dual Chips Solution, Stackable Design For Expanding Multiple CAN Channels, RPi HAT

2-Channel Isolated CAN Bus Expansion HAT For Raspberry Pi, Dual Chips Solution, Stackable Design For Expanding Multiple CAN Channels, Raspberry Pi HAT

2-CH CAN HAT+ is an isolated expansion board for Raspberry Pi, supports dual-channel CAN communication, and features multi-protection circuits, wide voltage input, and so on.

User Manual / Datasheet / Example Codes Etc.

• Designed for Raspberry Pi, support Raspberry Pi Zero/Zero W/Zero WH/2B/3B/3B+/4B/5.

• Standard HAT+ design, with onboard EEPROM chip.
• Adopts MCP2515 and SN65HVD230 dual-chip solution, allowing 2-channel CAN communication.
• Integrated power isolation, providing stable isolated voltage, requires no extra power supply for the isolated terminal.
• Onboard digital isolation chip, signal isolation communication is safer, more stable, and better anti-interference.
• Onboard SM24CANB (transient voltage suppressor), provides ESD protection and transient peak voltage protection.
• Onboard voltage conversion circuit, select 3.3V/5V operating voltage by jumper.
• Onboard 120Ω terminal resistor, enable through the jumper cap.
• Elicits the SPI control interface, for connecting with host control boards like STM32/Arduino.
• Provides complete supporting information manuals and demos

Specifications

• Input voltage: 5V, 7~36V
• Logic level: 3.3V/5V
• CAN controller: MCP2515
• CAN receiver: SN65HVD230
• Dimensions: 65.0x56.5mm
• Mounting hole diameter: 3.0mm

Package Includes

• 1x 2-CH CAN HAT+
• 1x Screws pack

What Can It Do?

Designed For Raspberry Pi Series
