801S Vibration Sensor Module

801S Vibration Sensor Module

The 801S Vibration Sensor Module is suitable for a wide range of applications, including industrial monitoring, security systems, and home automation projects. Its sensitivity allows it to detect subtle vibrations as well as more pronounced movements, making it a valuable tool for applications where precision and responsiveness are crucial.

This 801S module changes its resistance level once vibration is detected. It can turn into a switch if the vibration is high. According to the datasheet, it is gold-plated and can withstand 60 million shocks. This module is connected in a voltage divider which can be measured through its digital pinout. It’s a high sensitivity 801S Vibration Sensor module, which has one digital output pin(D0), When it detects some vibration up to a certain threshold, it can output High or Low level.

Features & Specs

• Main chip : LM393, vibration probe

• Working voltage : DC 3-5V
• With TTL level signal output indication

• Single channel signal output

• The output effective signal is high level, and the indicator light is off
•  Adjustable sensitivity (fine adjustment)
• Wide vibration detection range, no directionality
• With mounting holes, the firmware installation is flexible and convenient.

• Length: 10mm X 30mm wide X 20mm high
• Application :  It can be used in vibration testing occasions such as anti-theft devices, electronic locks, mechanical equipment vibration detection, bullseye counting detection in shooting range, etc.
