AOD4184 Isolation MOSFET Control Module
This module is a replacement for relay for driving motors and speed control applications of motors capable of rated capacity. It combines optocoupler and MOSFET for isolated and fast switching. Compatible with MCU and control board, 3V or 5V signal. As it is low power consumption, fast switching and no mechanical parts it is best alternative for relay in a battery powered application.
Features
- With optocoupler isolation, the control signal and the power of the controlled device are isolated, which greatly increases the rigidity of the interference.
- Compatible with MCU and Arduino control board, 3V or 5V signal
- High level start, low level stop, PWM speed regulation
- Widely used to control the start and stop of the motor, solenoid valve and other tributary equipment
- There are various specifications of MOS tube to provide choices,
- The signal input side can be welded to the terminal or pin itself, compatible breadboard
- Output can be soldered to the terminal or direct wire
- Module size 23mm X 16mm There are two 2mm diameter screw holes, hole spacing 8mm
Specifications
- Model: AOD4184 Isolation MOSFET Control Module
- MOSFET Type: D4184
- MOS tube: 40V 50A
Package Includes
- 1x AOD4184 Isolation MOSFET Control Module
