Name: AW9523B IO Expansion Board, I2C Interface, Expands 16 I/O Pins
Brand: WaveShare Electronics
SKU: 22132
Price: 437.78 INR
Availability: InStock

AW9523B IO Expansion Board, I2C Interface, Expands 16 I/O Pins

WaveShare Electronics

AW9523B IO Expansion Board, I2C Interface, Expands 16 I/O Pins

Based on 0 reviews. - Write a review

₹437.78

₹371.00 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 3
B2B GST Credit Available

Stock: 1 in Stock
SKU: 22132
Delivery Time
Bulk & B2B RFQ

Add to Cart

Buy Now

Plan to Buy Later ? Add to Wish List

AW9523B uses an I2C interface and allows using 4 expansion boards at the same time by modifying the i2c address and expanding up to 64 I/O ports.

Features

I2C bus allows expanding 16 I/O ports by just using two wires
Support driving 16-ch common anode constant current LED, 256-step linear dimming, current controllable
Output interrupt (INT) signal when changing the state of an input port
I2C address configurable by shorting the A0/A1 jumpers
Provides two connector options: PH2.0 header and/or solder pads, allows multi I2C modules to be stacked
Onboard voltage translator, compatible with 3.3V/5V level
Comes with development resources and manual (examples for Raspberry Pi / Micro:bit / Arduino / STM32)

Resources

User Guide and Instructions

Specifications

Operating Voltage	2.4V ~ 5.5V
Operating Temperature	-40 ~ 80 C
Low Standby Current	< 0.1uA
Controlling Interface	I2C
Expanding I/O	16

Header Definition

PIN	I2C Interface
VCC	Power Supply ( Support 3.3V / 5V)
GND	Ground
SDA and SCL	I2C Data Pin and I2C Clock Pin
INT	Interrupt Output
RST	Hardware Reset

Package Includes

AW9523B IO Expansion Board x1
PH2.0 6PIN wire x1
