Round 2D Codes Scanner Module, Barcode/QR code Reader, With LED Indicator, Small Size, Easy to Integrate
₹​2,118.00
₹​1,794.92 + 18% GST
All Inclusive, Shipping Calculated at Checkout
Assured Cashback of ₹ 18
B2B GST Credit Available
Price in reward points: 1795

Round 2D Codes Scanner Module, Barcode/QR code Reader, With LED Indicator, Small Size, Easy to Integrate

The Barcode Scanner Module (D) is a round 2D barcode scanner module with a round LED indicator, highly integrated and compact size, suitable for elevator and other code scanning applications. Adopts advanced image recognition algorithms, easy to decode various 1D or 2D codes. Onboard UART interface, can be easily integrated into kinds of embedded devices.


User Manual / Datasheet / Example Codes Etc.



Specifications

RESOLUTION640 × 480
SCAN ANGELShorizontal 70°, vertical 55°, roll 360°
SCAN MODESensing, Continuous
ACCURACY1D code ≥5mil
2D code ≥10mil
COMMUNICATION INTERFACEUART port (9600 8N1 by default)
LED INDICATORBlue: scanning
Green: decoded successfully
POWER SUPPLY3.3V
CURRENT120mA
PROTECTIONESD PROTECTIONcontact discharge 6 kV, air discharge ±12KV
IP PROTECTIONIP54 (front side)
TEMPERATUREOPERATING-30 ~ +70°C
STORAGE-40 ~ +80°C
WORKING HUMIDITY5%RH ~ 95%RH (non-condensing)



Decoding Capability

CODE TYPEBARCODEDEFAULT READABLEDEFAULT DISABLE
2DQR Code
DataMatrix
PDF417
1DEAN-13
EAN-8
UPC-A
UPC-E
Codabar
Code 128
Code 93
Code 39
Code 11
Interleaved 2 of 5
Industrial 2 of 5
Matrix 2 of 5
CS Databar (RSS)
MSI-Plessey



2D Codes Scanner Module

1D/2D Codes Recognition | Small Size | Screen Scanning




Package Includes




Pin Description

  1. GND: Ground
  2. RX: UART input pin
  3. TX: UART output pin
  4. VCC: 3.3V power supply
  5. NC: Reserved, not connected
  6. NC: Reserved, not connected



LED Indicator



Application Example



Dimensions
