2D Codes Scanner Module (C), Supports High Accuracy Barcode Scanning, Barcode/QR code Reader

2D Codes Scanner Module (C), Supports High Accuracy Barcode Scanning, Barcode/QR code Reader

The Barcode Scanner Module (C) is a Barcode/QR codes scanner module, by using the intelligent image recognition algorithm, it can decode the 1D or 2D code on paper or screen fastly and accurately. Supports a variety of barcode formats and high accuracy, high speed and high contrast barcode scanning. Onboard USB and UART interfaces, can be directly plugged into a computer, or be easily integrated into kinds of embedded devices.
User Manual / Datasheet / Example Codes Etc.

Features

• RESOLUTION : 640 × 480
• ACCURACY : 1D Codes 3mil 2D Codes 5mil
• SCAN ANGELS : pitch ±60°, skew ±60°, roll 360°
• POWER SUPPLY : 5V / 3.3V
• CURRENT OPERATING : 250mA
• CURRENT STANDBY : 20mA
• CURRENT BOOT : 258mA
• TEMPERATURE OPERATING : -20 ~ +60°C
• TEMPERATURE STORAGE : -40 ~ +70°C

Onboard ResourceProduct Show

Dimensions
