DB9 Male + Female (Set) Screw Terminal to RS232/RS485 Conversion Board With Shell & Nut
This DB9 Male and Female Screw Terminal Set allows for easy, tool-free wiring in RS232 and RS485 communication systems, facilitating reliable data transmission in industrial and DIY applications. Each board is equipped with secure screw terminals, simplifying connections without the need for soldering, and enabling quick integration into RS232 and RS485 networks. The set includes a durable shell and nut, providing robust strain relief and protection for long-term use. Ideal for prototyping, testing, and permanent installations, this set is designed to streamline data communication setups, making it ideal for engineers, technicians, and hobbyists looking for a versatile, plug-and-play solution.
Note: Image shown is a representation only, Actual image may be differ.
Features
- Tool-Free Wiring: Screw terminals allow for quick, solder-free connections, making setup easier and more flexible.
- Universal Compatibility: Supports both RS232 and RS485 protocols, enabling versatile use across different communication systems.
- Robust Housing: Includes a protective shell with a nut for secure mounting, providing strain relief and shielding the connectors.
- Plug-and-Play Design: Ideal for rapid prototyping, testing, and permanent installations in industrial or DIY applications.
- Reliable Performance: Ensures stable signal transmission for data communication projects.
Specifications
- Connector Type: DB9 Male and Female (Set)
- Compatibility: RS232 / RS485 communication protocols
- Connection Type: Screw terminals, no soldering required
- Shell & Nut: Included for enhanced protection and secure mounting
- Material: Durable plastic and metal housing
- Color: Black
- Board size: 4.0cm * 3.1cm
Application
- Industrial Control Equipment
- Serial Data Transmission
- Tax Control Machine
- Industrial Instrument
- Device Management
- Data Network
- Cash Machine
- Computer
- Modem
Package Includes
- 1x DB9 Male + Female (Set) With Shell
- 1x Nut Set
