DWIN 1.54 Inch Circular Rotary LCD, No Touch, IPS TFT 240x240 LCD Display With Enclosure DMG24240C015_13WN (Commercial Grade)
The DWIN 1.54 Inch Circular Rotary LCD, a cutting-edge display solution designed for applications where a compact, round form factor is essential. With a resolution of 240x240 pixels and an IPS TFT panel, this display promises vibrant and sharp visuals, making it an ideal choice for projects demanding clarity and precision.
Features
- Based on T5L0, running DGUS II system, commercial grade
- Circular rotary screen with encoder shell
- 240*240 Pixels resolution, 262K Colors, IPS-TFT-LCD, Wide viewing angle
- Active Area (A.A.): Diameter=26.8mm
- >20000 hours (Time of the brightness decaying to 50% on the condition of continuous working with the maximum brightness)
Specifications
Display
- Color : 18-bit, 6R6G6B
- LCD Type : IPS, TFT-LCD
- Viewing Angle : Wide viewing angle, 85°/85°/85°/85°(L/R/U/D)
- Display Area（A.A）: Diameter=26.8mm
- Resolution : 240*240
- Backlight : LED
Operating Environment
- Operating Temperature : -20~70℃(5V @ 60% RH)
- Storage Temperature : -30~80℃
- Working Humidity : 10%~90%RH, typical value of 60% RH
- Conformal Coating : None
Electrical Specifications
- Rated Power : <1W
- Power Voltage : 4.5~5.5V, typical value of 5V
- Operation Current : VCC=5V, max backlight: 62m, VCC=5V, backlight off: -
