DWIN 1.54 Inch IPS LCD, Capacitive Touch, IPS TFT 240x240 350nit LCD Display, DMG24240C015_03WTC (Commercial Grade)

This is an DWIN 1.54 Inch Small Size IPS LCD, Capacitive Touch, IPS TFT 240x240 350nit LCD Display. The Dwin 1.54inch IPS LCD Based on T5L0, running DGUS II system, Which comes with Capacitive touch, 240x240 resolution, 350nit brightness & 18-bit 6R6G6B colors.


Datasheet


Features

  • Based on T5L0, running DGUS II system
  • IPS-TFT-LCD, Wide viewing angle
  • Operation voltage: 4.5~5.5V, typical value of 5V
  • Color: 18-bit 6R6G6B
  • Wide viewing angle, 85°/85°/85°/85° (L/R/U/D)
  • 1.54-inch, 240*240 Pixels resolution


Specifications

Display

  • Color : 18-bit 6R6G6B
  • LCD Type : IPS
  • Viewing Angle : Wide viewing angle, 85°/85°/85°/85° (L/R/U/D)
  • Display Area(A.A): 27.5mm (W)×27.5mm (H)
  • Resolution : 240x240
  • Backlight : LED
  • Brightness : DMG24240C015_03WTC : 350nit


Touch parameters

  • Type : CTP (Capacitive touch panel)
  • Structure : G+G structure with surface cover of tempered glass
  • Touch Mode : Support point touch and drag
  • Surface Hardness : 6H
  • Light Transmittance : Over 90%
  • Life : Over 1,000,000 times touch


Reliability Test

  • Working Temperature  : -20℃~70℃ (5V @ 60% RH)
  • Storage Temperature : -30℃~80℃
  • Working Humidity : 10%~90%RH, typical value of 60% RH


Voltage & Current

  • Power Voltage : 4.5~5.5V
  • Operation Current : VCC = +5V, Backlight on: 90mA, VCC = +5V, Backlight off: 60mA


Interface

  • LCM interface : FPC40_0.5mm, RGB interface
  • RTP interface : FPC4_1.0mm
  • CTP interface : 6Pin_0.5mm, IIC interface
  • Baudrate : 3150~3225600bps, typical value of 115200bps
  • Output Voltage : Output 1, Iout = -4mA;3.0~3.3 V, Output 0, Iout =4mA;0~0.3 V
  • Input Voltage(RXD): Input 1,2.4~5.0V, Input 0,0~0.5V
  • Interface : UART2:ON=TTL/CMOS;, UART4:ON=TTL/CMOS; (OS configuration)
  • User interface : Interface Cable 10Pin_1.0mm
  • Flash : 16MBytes NOR Flash, for fonts, pictures and audio files. Rewrite cycle: over 100,000 times
  • Buzzer : 3V passive buzzer. Power: <1W
  • SD interface : FAT32. Download files by SD interface can be displayed in statistics. Download rate: 4Mb/s
  • PGT05 interface : When product crashes by accident, you can use PGT05 to update DGUS kernel and make the product return to normal
