DWIN 7inch HMI LCD, Capacitive Touch, TN TFT 800x480 800nit High Brightness LCD Display, DMG80480T070_09WTC (Industrial Grade)
The DWIN 7-inch HMI LCD, model DMG80480T070_09WTC, is an advanced industrial-grade display designed for a wide range of applications. This high-quality display features a capacitive touch panel, offering a smooth and responsive touch experience. With a resolution of 800x480 pixels, the TN TFT panel delivers clear and vibrant visuals, making it ideal for detailed graphical interfaces.
Features
- 7.0 Inch,800*RGB*480,262K Colors, TN Display, High brightness
- Anti-UV, with conformal coating, Capacitive touch screen;
- TTL/RS232 User interface; 8Pin_2.0mm cable
- Download via SD card or on-line UART serial port, or optional USB and WiFi
- Developed by DWIN DGUS V7.6 GUIs Development, no code required
- DGUS Ⅱ/TA(Instruction set) two development mode available
- View Angle: 70/70/50/70(L/R/U/D)
- Fast running dual core, GUI &OS core of 8051 processor.
Specifications
- Display Parameters
- LCD Type: TN, TFT LCD
- Viewing Angle: Normal viewing angle, 70°/70°/50°/70° (L/R/U/D)
- Resolution: 800×480 pixels (support 0°/90°/180°/270°)
- Color: 18-bit 6R6G6B
- Active Area (A.A.): 154.08mm (W)×85.92mm (H)
- Backlight Mode: LED
- Backlight Service Life: >30000 hours (Time of the brightness decaying to 50%on the condition of continuous working with the maximum brightness)
- Brightness: DMG80480T070_09WTC: 800nit
- Brightness Control: 0~100 grade (When the brightness is adjusted to 1%~30%of the maximum brightness, flickering may occur and is not recommended to use in this range)
- Touch Parameters
- Type: CTP (Capacitive touch panel)
- Structure: G+G structure with surface cover of tempered glass
- Touch Mode: Support point touch and drag
- Surface Hardness: 6H
- Light Transmittance: Over 90%
- Life: Over 1,000,000 times touch
- Electrical specifications
- Rated Power: <5W
- Operating Voltage: 6~36V, typical value of 12V
- Operating Current: 340mA: VCC=12V, max backlight - 120mA: VCC=12V, backlight off
- Recommended power supply: 12V 1A DC
- Operating environment
- Operating Temperature: -20℃~70℃ (12V @ 60% RH)
- Storage Temperature: -30℃~80℃
- Conformal Coating: Yes
- Operating Humidity: 10%~90%RH, typical value of 60% RH
