Name: Universal E-Paper Raw Panel Driver Shield (B) For NUCLEO / Arduino, Onboard MX25R6435F Flash Chip, Supports Expanding External RAM
Brand: WaveShare Electronics
SKU: 26506
Price: 982.00 INR
Availability: InStock

Universal E-Paper Raw Panel Driver Shield (B) For NUCLEO / Arduino, Onboard MX25R6435F Flash Chip, Supports Expanding External RAM

WaveShare Electronics

Universal E-Paper Raw Panel Driver Shield (B) For NUCLEO / Arduino, Onboard MX25R6435F Flash Chip, Supports Expanding External RAM

Based on 0 reviews. - Write a review

₹982.00

₹832.20 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 8
B2B GST Credit Available

Price in reward points: 832

Stock: 1 in Stock
SKU: 26506
Delivery Time
Bulk & B2B RFQ

Add to Cart

Buy Now

Plan to Buy Later ? Add to Wish List

Universal E-Paper Raw Panel Driver Shield (B) For NUCLEO / Arduino, Onboard MX25R6435F Flash Chip, Supports Expanding External RAM

The Universal E-Paper Raw Panel Driver Shield (B) is an advanced and versatile module designed for seamless integration with NUCLEO and Arduino development platforms. This shield is specifically engineered to drive e-paper displays efficiently, offering a wide range of applications in the realm of electronic paper technology.

User Manual / Datasheet / Example Codes Etc

Features

Standard Arduino connectivity, compatible with host boards like nRF528xx, UNO, Leonardo, NUCLEO, XNUCLEO
Onboard voltage translator, compatible with 3.3V/5V MCUs
Onboard MX25R6435F Flash chip
Reserved external RAM soldering pads for expanding more space
Comes with online resources and manual

Specifications

OPERATING VOLTAGE : 3.3V/5V
INTERFACE : 3-wire SPI, 4-wire SPI
FLASH MEMORY SIZE : 64M-bit / 8M-byte
RESERVED RAM PACKAGE : SOIC-8
OUTLINE DIMENSIONS : 53.34 × 53.34mm

Package Includes

e-Paper Shield (B) x1
e-Paper Adapter with 24PIN FFC cable ~200mm x1

Comes With Adapter Board And FFC Cable

What's On Board

1. Waveshare e-Paper driver resistor selection

2. 3-wire/4-wire SPI selection

3. 24PIN e-paper connector

4. Arduino standard interface

5. Voltage translator

6. Flash Chip

7. DIP switch

8. Arduino board SPI communication selection (ICSP by default)

9. ICSP header

10. Power selection

IOREF by default

11. Reserved RAM soldering pads

Dimensiosn
