Ebyte E15-PCIE-T1 PCIe Adapter Evaluation Board for SX1262/SX1268 LoRaWAN Gateway Module

Ebyte E15-PCIE-T1 PCIe Adapter Evaluation Board for SX1262/SX1268 LoRaWAN Gateway Module

E15-PCIE-T1 wireless module adapter board is a test board developed by Chengdu Ebyte for the mini PCI-e interface LoRa wireless module. The PCIE adapter board is mainly aimed at the embedded application of the E22 series LoRa modules launched by our company. , and equipped with ESD protection, supporting multiple systems and multiple baud rates. Developers can easily connect a variety of peripheral devices through jumpers according to actual needs.

Datasheet

Specifications

• Communication Interface: RS232/RS485/USB
• Compatible Modules: E22-400T33E, E22-230T33E, E22-400T30E, E22-230T30E
• Operating temperature: -40 ~ +85℃
• Working humidity: 10% ~ 90%
• Storage temperature: -40 ~ +125℃
• Dimensions: 64.5*54mm
