Name: Ebyte E22-900M33S SX1262 868~915MHz LoRa Wireless Module - 16KM Range - SPI Interface
Brand: Ebyte
SKU: 06585
Price: 1359.00 INR
Availability: OutOfStock

Ebyte E22-900M33S SX1262 868~915MHz LoRa Wireless Module - 16KM Range - SPI Interface

Ebyte

Ebyte E22-900M33S SX1262 868~915MHz LoRa Wireless Module - 16KM Range - SPI Interface

Based on 0 reviews. - Write a review

₹1,359.00

₹1,151.69 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 12
B2B GST Credit Available

Price in reward points: 1152

Stock: 0 in Stock
SKU: 06585
Delivery Time
Bulk & B2B RFQ

Buy Now NOTIFY WHEN AVAILABLE

Plan to Buy Later ? Add to Wish List

Ebyte E22-900M33S SX1262 868~915MHz LoRa Wireless Module - 16KM Range - SPI Interface

E22-900M33S is independently developed based on the new generation LoRa radio frequency chip SX1262 produced by Semtech in the United States. It has a maximum power of 2W and is suitable for 868/915MHz patch-type LoRa wireless modules. It uses an industrial-grade high-precision 32MHz crystal oscillator. Compared with the previous generation LoRa transceiver, the anti-interference performance and communication distance have been improved, further widening the gap with products with FSK and GFSK modulation methods. This product can cover an ultra-wide applicable frequency range of 850 to 930MHz and is backward compatible with SX1278 and SX1276. Since this module is a pure radio frequency transceiver module, it needs to use an MCU driver or a dedicated SPI debugging tool.

Datasheet

Features

SX1278 module, the SX1262 module has the significant advantages of lower power consumption, faster speed, and longer distance
Under ideal conditions, the communication distance can reach 16 km
Built-in PA +LNA , greatly improving communication distance and communication stability
The maximum transmit power is 2 W, multi-level software adjustable
Support global license-free ISM 868/915 MHz frequency band
Supports multiple modulation modes, LoRaTM /GFSK
LoRaTM mode supports data transmission rates from 0.3 k to 62.5 kbps
G FSK mode supports data transmission rate up to 300kpbs
Backwards compatible with SX1278/SX1276 series RF transceiver
FIFO has large capacity and supports 256Byte data cache
SF5 spreading factor introduced to support dense networks
Supports 3.3 ~ 5.5V power supply, and any power supply greater than 5 V can ensure the best performance
Industrial grade standard design, supports long-term use at -40 ~ + 85 ℃
Optional dual antennas (IPEX/stamp hole) facilitate user secondary development and integration

Specifications

Chip solution: SX1262
Working Frequency: 868~930MHz
Communication distance: 16km
Supply Voltage: 3.3V to 5V
Antenna interface: Stamp hole/IPEX
Working temperature: -40 to +85℃
Dimension: 24*38.5mm

Applications

Home security alarm and remote keyless entry
Smart home and industrial sensors, etc.
Wireless alarm security system
Building automation solutions
Wireless industrial grade remote control
Advanced Meter Infrastructure (AMI )
Automotive industry applications
