Ebyte E70-900M14S1B CC1312R 868~915MHz 14dBm1.5km Wireless SoC Module

Ebyte E70-900M14S1B CC1312R 868~915MHz 14dBm1.5km Wireless SoC Module

E70-900M14S1B adopts the original imported CC1312R from Texas Instruments (TI). It integrates a single-chip microcomputer and wireless transceiver, and uses a 48MHz industrial-grade high-precision low-temperature drift crystal oscillator to ensure its industrial characteristics and stable performance.

The CC1312R chip has a built-in powerful 48MHz Arm Cortex-M4F processor, and has abundant peripheral resources such as UART, I2C, SPI, ADC, DMA, and PWM. The module leads to all the IO ports of the single-chip microcomputer, which can be used for multi-directional development

Datasheet

Features

• Developed based on CC1312R, built-in powerful 48MHz Arm Cortex-M4F processor
• With 48MHz temperature compensated crystal oscillator, industrial-grade standard design
• 352KB system programmable flash memory, 256KB ROM for protocol and library functions
• 8KB cache SRAM (available as general-purpose RAM), 80KB ultra-low leakage SRAM, SRAM adopts parity check protection to ensure high reliability of operation RSSI signal strength reading
• Air wake-up, that is, low power consumption function, suitable for battery-powered solutions
• Ultra-low receiving current, its receiving current is only half of similar products
• The maximum transmit power is 25mW, and the software is multi-level adjustable
• For European license-free frequency band ISM 868MHz and North America license-free ISM 915MHz frequency band
• Air transmission rate: 20～1000kbps
• 2.2～3.8V power supply, power supply greater than or equal to 3.3V can guarantee the best performance
• Under ideal conditions, the communication distance can reach 1.5km
• Dual antennas are optional (IPEX/stamp hole), which is convenient for users to develop and integrate.

Specifications

• IC: CC1312R
• Frequency: 850~930MHz
• Power: 14dBm
• Distance: 1.5km
• Antenna: IPEX/stamp hole
• Operating Temperature: -40 to 85℃
• Size: 16*26mm
• Package: SMD

Applications

• Smart home and industrial sensors, etc.
• Security systems, positioning systems
• Wireless remote control, drone
• wireless game remote
• healthcare products
• Wireless voice, wireless headphones
• Automotive industry applications.
