Ebyte E77-900M22S STM32WLE5CCU6 868~915MHz 22dBm 5.6Km LoRaWAN Node Wireless Module - UART Interface

Ebyte E77-900M22S STM32WLE5CCU6 868~915MHz 22dBm 5.6Km LoRaWAN Node Wireless Module - UART Interface

E77-900M22S is a standard LoraWan node module developed by Ebyte. It supports LoRaWAN 1.0.4 EU868, US915, AU915, AS923, IN865, KR920, RU864 standards, CLASS-A/CLASS-C node types, and ABP/OTAA network access methods. At the same time, the module has a variety of low-power modes, and the external communication interface uses a standard UART. Users can access the standard LoRaWAN network through simple configuration of AT commands. It is an excellent choice for current IoT applications.

Datasheet

Features

• Under ideal conditions, using transparent transmission protocol , the communication distance can reach 5.6km
• Under ideal conditions, using LoRaWAN standard firmware, the communication distance can reach 3.5 km
• The maximum transmit power is 21.5dBm , multi-level software adjustable
• E77-400M22S supports the global license-free ISM 868/915MHz frequency band
• E77-900M22Ssupports Lo Ra WAN 1.0.4 EU868/US915/AU915/AS923/IN865/KR920/RU864 standard
• E77-900M22S supports two device types: Class A and Class C
• ~12SF spreading factors launched to support dense networks
• Supports 1.8 ~ 3.6 V power supply, and any power supply greater than 3.3 V can ensure the best performance
• The external crystal oscillator uses 32.768KHz, 32MHz high-precision industrial-grade crystal oscillator
• 14.0*20.0*2.7mm small size patch package, conducive to system integration development
• Industrial grade standard design, supports long-term use at -40~+85℃
• Optional dual antennas (IPEX/stamp hole) facilitate user secondary development and integration

Specifications

• Chip solution: STM32WLE5CCU6
• Carrier frequency: 868~930MHz
• Transmit power: 22dBm
• Communication distance: 5600m
• Communication: interface: UART、SPI、I²C、GPIO、ADC
• Antenna type: IPEX/stamp hole
• Product size: 14*20mm
• Operating Temperature: -40 to 85℃
• Working Humidity: 10 to 90%
• Storage Temperature: -40 to 125℃

Applications

• Smart home and industrial sensors, etc.
• Security systems, positioning systems
• Wireless remote control, drone
• wireless game remote
• healthcare products
• Wireless voice, wireless headphones
• Automotive industry applications.
