Name: Ebyte E80-400M2213S LR1121 410~493MHz/2.4GHz LoRa Dual-band Wireless RF Transceiver Module
Brand: Ebyte
SKU: 06575
Price: 809.00 INR
Availability: OutOfStock

Ebyte E80-400M2213S LR1121 410~493MHz/2.4GHz LoRa Dual-band Wireless RF Transceiver Module

Ebyte

Ebyte E80-400M2213S LR1121 410~493MHz/2.4GHz LoRa Dual-band Wireless RF Transceiver Module

Based on 0 reviews. - Write a review

₹809.00

₹685.59 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 7
B2B GST Credit Available

Price in reward points: 686

Stock: 0 in Stock
SKU: 06575
Delivery Time
Bulk & B2B RFQ

Buy Now NOTIFY WHEN AVAILABLE

Plan to Buy Later ? Add to Wish List

Ebyte E80-400M2213S LR1121 410~493MHz/2.4GHz LoRa Dual-band Wireless RF Transceiver Module

E80-400M2213S is a dual-band SMD LoRa hardware SPI wireless module independently developed based on SEMTECH's LoRa Connect™ LR1121 chip for multi-band global connectivity, with transmit powers of 22dBm and 13dBm respectively. An industrial-grade 48MHz high-precision low-temperature drift crystal oscillator is integrated inside the module. LR1121 is SEMTECH's third-generation ultra-low power LoRa transceiver. It provides multi-band LoRa and long-range frequency hopping spread spectrum (LR-FHSS) communications based on Sub-GHz and 2.4 GHz ISM bands, as well as satellite s-band connectivity. At the same time, it remains configurable to meet different application requirements and proprietary protocols.

Datasheet

Features

Low power consumption and high sensitivity LoRa/(G)FSK half-duplex RF transceiver
Global ISM band support ranges from 150-960MHz ( Sub- GHz ) and 2.4 GHz, as well as 2.1 GHz S-band
Built-in low noise figure RX front end, enhanced LoRa / ( G ) FSK sensitivity
Maximum transmit power 2 2 dBm @ Sub - GHz/ 13 dBm @ 2.4GHz, software-adjustable in multiple levels
Under ideal conditions, the communication distance can reach 5.6 km @ 433MHz / 5.6km@ 868 MHz / [email protected]
The chip has a built-in LR-FHSS modulator , which supports remote frequency hopping spread spectrum in the 2.4 GHz band
Integrated PA regulator power selector simplifies dual power supply design, achieving a maximum RF output power of+15/+22dBm ( Sub- GHz only ) on a single board
Built-in DC-DC power supply circuit, lower power consumption and more stable system
Capable of supporting multi-regional BOMs worldwide, with circuits that adapt matching networks to meet regulatory restrictions
with SX126x devices under Sub-GHz communication and compliant with LoRa The LoRaWAN ® standard defined by the Alliance®
with SX12 8x devices ( except FLRC modulation ) at 2.4GHz communication and compliant with LoRa The LoRa standard defined by Alliance®
Hardware supports AES-128 encryption/decryption algorithms
The module includes 48M high-speed crystal oscillator/32.768k low-speed crystal oscillator
Industrial-grade standard design, supports long-term use at -40～+85℃
Dual antennas are optional (IPEX/stamp hole), users can choose to use according to their needs

Specifications

Chip: LR1121IMLTRT
Working frequency: 410-493M/2.4GHz
Transmitting power: 21.5/13dBm
Communication distance: 5.6/2.6km
Working Voltage: 3.3V
Communication interface: SPI
Antenna: IPEX-1/stamp hole
Working Temperature: -40 to +85℃
Working Humidity: 10 to 90%
Storage Temperature: -50 to +150℃
Dimensions: 26*16mm

Applications

Smart Meter
Building Automation
Agricultural Sensors
Smart City
Retail Store Sensors
Asset Tracking
Street lighting
Reversing radar
Environmental Sensors
Safety Sensors
Remote control application
Smart Home
Radio-controlled toys and drones
