Ebyte E07-433M20S CC1101 433MHz 20dBm 2km SPI Wireless RF Transceiver Module

Ebyte E07-433M20S CC1101 433MHz 20dBm 2km SPI Wireless RF Transceiver Module

E07-433M20S is a self-developed, small-size, 433MHz SMD wireless module with a maximum tx power of 100mW based on CC1101 of Texas Instruments.

Datasheet

Features

• The measured communication distance can reach 2 km
• Maximum transmission power of 100mW, software multi-level adjustable
• Support the global license-free ISM 433 MHz band
• Support air date rate of 0.3kbps～500kbps
• Support multiple modulation modes (OOK, ASK, GFSK, 2-FSK, 4-FSK and MSK)
• Independent 64-byte RX FIFO and TX FIFO
• Support 2.1V~3.6V power supply, power supply over 3.3 V can guarantee the best performance
• Industrial grade standard design, support -40 ~ 85 °C for working over a long time
• IPEX and stamp hole optional, good for secondary development and integration
• Support RSSI (received signal strength indication) and LQI (link quality indication)
• It connects to MCU through 4-wire SPI interface, and provides two universal digital output pins with settable functions.

Specifications

• IC: CC1101
• Frequency: 425～525MHz
• Power: 20dBm
• Distance: 2km
• Communication Interface: SPI
• Antenna: IPEX/STAMP

• Operating temperature: -40 to +85℃

• Dimensions: 18 * 32 mm
• Package: SMD

Applications

• Home security alarm and remote keyless entry
• Smart home and industrial sensors, etc.
• Wireless alarm security systems
• Building automation solutions
• Wireless industrial-grade remote control
• Intelligent agriculture and oilfield solutions
• Health care products
• Advanced Meter Reading Architecture(AMI)
• Automotive industry applications.
