Name: Ebyte E810-U15H USB to RS485/232/422/TTL Converter - FT232-HL Chip Based - Industrial Grade - Support Windows 10 - Driver Free Plug & Play
Brand: Ebyte
SKU: 06904
Price: 2582.00 INR
Availability: InStock

Ebyte E810-U15H USB to RS485/232/422/TTL Converter - FT232-HL Chip Based - Industrial Grade - Support Windows 10 - Driver Free Plug & Play

Ebyte

Ebyte E810-U15H USB to RS485/232/422/TTL Converter - FT232-HL Chip Based - Industrial Grade - Support Windows 10 - Driver Free Plug & Play

This product qualifies for Free Surface Shipping !

All orders with value above 1999+GST are eligible for free delivery in Surface mode. (Not applicable for B2B offline orders)

Based on 0 reviews. - Write a review

₹2,582.00

₹2,188.14 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 22
B2B GST Credit Available

Price in reward points: 2188

Stock: 2 in Stock
SKU: 06904
Delivery Time
Bulk & B2B RFQ

Add to Cart

Buy Now

Plan to Buy Later ? Add to Wish List

Ebyte E810-U15H Industrial Grade USB to RS485/232/422/TTL Converter - FTDI FT232-HL Chip Based - Support Windows 10 - Driver Free Plug & Play

E810-U15H is a high-speed USB-RS-232/RS-422/RS-485/TTL conversion interface. It supports up to 12M serial port rate and can convert USB signals into RS-232/RS-422/RS-485/3.3V/5V TTL signals without external power supply. Each interface provides surge protection. E810-U15H interface converter can provide reliable connection for point-to-point and point-to-multipoint communication. Each point-to-multipoint converter can allow the connection of 128 RS-422 or RS-485 interface devices.

User Manual

Features

The USB interface adopts Type-c interface, which is convenient, easy to use and reliable; • Supports 3.3VTTL and 5V TTL full duplex communication
Supports three-wire RS-232 full duplex communication
Supports four-wire RS-422 full-duplex communication
Supports two-wire RS-485 half-duplex communication
A 1200 matching resistor (1/4W) can be connected in parallel at the line terminals when multiple devices are connected externally to the converter or when communicating over long distances

Specifications

Interface communication: USB/RS485/RS232/TTL
Chip Solution: FT232H
USB protocol standard: USB2.0, backward compatible with USB1.0, USB1.1
USB interface standard: type-c interface
RS-232 interface standard: Standard DB9 male connector, full duplex 2: RXD 3: TXD5:GND
RS-485 interface standard: 2P 5.08mm terminal block, half duplex
RS-422 interface standard: 4P5.08mm terminal block, full duplex
TTL interface standard: 4P 5.08mm terminal block, compatible with 3.3V and 5V levels
Power output: 2P 5.08mm terminal block, 5V, maximum output current 100mA
Working temperature and humidity: -40~+85°C5%~95%RH (no condensation)
Storage temperature and humidity: -40~+105C, 5%~95%RH (no condensation)
Dimensions: 113x72x34mm

Package Includes

1x Ebyte E810-U15H USB to RS485/232/422/TTL Converter
1x USB C Data Cable
1x User Manual
1x Terminal Blocks
