Name: IOTROUTER EC300P-LAN 10.1inch Touchscreen Multi-Interface ARM Industrial Computer - Based on Rockchip RK3562J - 2GB RAM + 16GB eMMC - Support Linux OS
Brand: IOTROUTER
SKU: 08293
Price: 45842.00 INR
Availability: OutOfStock

IOTROUTER EC300P-LAN 10.1inch Touchscreen Multi-Interface ARM Industrial Computer - Based on Rockchip RK3562J - 2GB RAM + 16GB eMMC - Support Linux OS

New

IOTROUTER

IOTROUTER EC300P-LAN 10.1inch Touchscreen Multi-Interface ARM Industrial Computer - Based on Rockchip RK3562J - 2GB RAM + 16GB eMMC - Support Linux OS

This product qualifies for Free Surface Shipping !

All orders with value above 1999+GST are eligible for free delivery in Surface mode. (Not applicable for B2B offline orders)

Based on 0 reviews. - Write a review

₹45,842.00

₹38,849.15 + 18% GST

All Inclusive, Shipping Calculated at Checkout

Assured Cashback of ₹ 388
B2B GST Credit Available

Price in reward points: 38849

Stock: 0 in Stock
SKU: 08293
Delivery Time
Bulk & B2B RFQ

Buy Now NOTIFY WHEN AVAILABLE

Plan to Buy Later ? Add to Wish List

IOTROUTER EC300P-LAN 10.1inch Touchscreen Multi-Interface ARM Industrial Computer - Based on Rockchip RK3562J - 2GB RAM + 16GB eMMC - Support Linux OS

The EC300 series Touchscreen Multi-Interface ARM Industrial Computer is a high-performance ARM-based industrial computer equipped with the Rockchip RK3562J quad-core processor (1.8GHz), featuring a 1TOPS NPU and a dedicated 3D GPU. It supports lightweight AI vision tasks and 4K video decoding. Pre-installed with Embedded Linux, it natively integrates Node-RED for visual programming, NeuronEX-Lite for industrial protocol gateway functionality (supporting 100+ protocols), and the FUXA zero-code SCADA platform. This provides an integrated solution for edge logic development, data acquisition, and visualization.

Datasheet

Features

Audio-Visual Monitoring (EC300P): Direct HDMI connection to large displays + 3.5mm audio for alerts.
Visual Programming: Node-RED drag-and-drop workflow design for zero-code control strategy development and minute-level deployment of intelligent applications.
Protocol Hub: NeuronEX supports 100+ protocols (e.g., Modbus, OPC UA) with only 200MB resource footprint and concurrent handling of hundreds of data points.
Zero-Code SCADA: FUXA drag-and-drop interface enables millisecond-level data visualization, addressing slow development cycles and expensive licensing of traditional SCADA systems.
Passive Cooling Architecture: Aluminum alloy casing + fin array + direct SOC-to-metal contact enables stable fanless operation.
Remote O&M: Free software tools for configuration, debugging, and firewall management.
Full Isolation & Protection: Electrically isolated interfaces with ESD/surge protection. Hardware watchdog timer prevents system lockups.

Specifications

Display: 10.1-inch industrial-grade capacitive touchscreen, 1024 × 600 resolution
Processor: Rockchip RK3562J Quad-Core ARM Cortex-A53, up to 1.8GHz
Memory: 2GB LPDDR4 RAM
Storage: 16GB eMMC Flash
Operating System: Embedded Linux
GPU: Mali-G52 2EE GPU
AI Performance: 1 TOPS NPU (platform dependent)
Touch Panel: Multi-touch capacitive touchscreen
Storage Expansion: MicroSD card slot
SSD Support: M.2 NVMe SSD expansion
Display Output: HDMI
USB Ports: 2 × USB 2.0, 1 × USB Type-C (Debug)
Ethernet: 1 × Gigabit Ethernet, 1 × Fast Ethernet
Audio: 3.5mm Audio Jack
Power Input: 9V–36V DC
Operating Temperature: -40°C to +85°C
Applications: Industrial automation, HMI, IoT gateway, Edge computing, SCADA, Factory control systems, Smart manufacturing

Package Includes

1xEC300P-LAN 10.1inch Touchscreen Multi-Interface ARM Industrial Computer - Based on Rockchip RK3562J - 2GB RAM + 16GB eMMC - Support Linux OS
